Rackmount-Business KVM

Direct: 8, Maximum: 256 (via Daisy-chain), Port Selection: OSD, Hotkey, Pushbutton, Console Ports: 1 x SPHD-18 Male (Yellow), KVM Ports: 8 x SPHD-15/17 Female (Yellow), Daisy Chain Ports: 1 x DB-25 Female (Black), 1 x DB-25 Male (Black). The CS1708A-AT-U KVM switch is a control unit that allows access to multiple computers from a single PS/2 or USB console (keyboard, mouse, and monitor). A single CS1708A-AT-U can control up to 8 computers.

Direct: 16, Maximum: 256 (via Daisy-chain), Console Ports: 4 x USB Type A Female, KVM Ports: 16 x RJ-45 Female, 1 x DB-25 Male (Black), Power: 1 x IEC 60320/C14, Station ID: 1 x 7-segment LED display (Orange), Keyboard / Mouse: PS/2; USB, Power Consumption: AC110V:9.7W:63BTU, Housing: Metal. The KH2516A-AX-U switch is a control unit that allows IT administrators to access and control multiple computers from two PS/2 or USB KVM consoles (one bus). Operators working at up to two consoles can independently and simultaneously take control of up to 16 computers.

Aten CL3100NX-ATA-AU Ultra Short Depth Single Rail Widescreen Rackmount, LCD Console, Direct-1, KVM Ports 1 x SPHD Female (Yellow), 1 x 3.5mm Audio Jack Female (Green), Resolution 1366 x 768 @ 60Hz, Contrast Ratio 700:1, Resolution up to 1920 x 1200 @ 60Hz;, 1366 x 768 @ 60 Hz, DDC2B, Metal + Plastic, Single Rail. The CL3100 USB VGA LCD Console is a short depth single rail LCD KVM console featuring an 18.5" LED-backlit widescreen LCD monitor with an integrated keyboard and touchpad.

Aten CL3108NX-ATA-AU 8-port Short Depth Ps/2-usb Vga Single Rail, Maximum 128 (via Cascade), KVM Ports 8 x SPHD Female (Yellow), Firmware Upgrade: 1 x 3.5mm Audio Jack Female (Black), Power: 1 x IEC 60320/C14, External Mouse Port: 1 x USB Type A Female (Front), Port Selection: 8 x Pushbutton, Reset: 1 x Semi-recessed Pushbutton, Firmware Upgrade: 1 x Slide Switch, Power: 1 x Rocker Switch, LCD Control: 4 x Pushbutton.

Operating Temperature: 0 - 40°C, Storage Temperature: -20 - 60°C, Humidity: 0 - 80% RH, Non-Condensing, Input: 4 x Captive Screw Connector, 5 Pole (Green), Audio signal type: stereo, balanced/unbalanced.

Direct: 8, Maximum: 128 (via Cascade), Port Selection: OSD, Hotkey, Pushbutton, RS-232 Commands, Firmware Upgrade: 1 x RJ11 Female (Black), Power: 1 x DC Jack, USB Hub: 2 x USB3.1 Gen1 Type A Female (Blue; 2 x front), Port Selection: 8 x Pushbutton, Reset: 1 x Semi-recessed Pushbutton, Firmware Upgrade Recovery: 1 x Slide Switch, On Line /Selected: 8 (Orange), Power: 1 (Green), USB Link: 8 (Green), Keyboard / Mouse: USB, Housing: Metal, Warranty: 01 Year The ATEN CS19208 8-Port USB 3.0 4K DisplayPort KVM Switch can effectively access and control up to 8 DisplayPort computers from a single USB keyboard,

Brand: Aten, Model: CL5716N-ATA-AU, LCD Display: 1x SPHD-18 Male (Yellow), 1x USB Type-A Female (White), 16x SPHD-15/17 Female (Yellow), 1x DB-25 Male (Black), 1x RJ-11 Female, 1x 3-prong AC Socket, 1x USB Type-A Female (White). The CL5716 Slideaway LCD KVM Switch is a control unit that allows access to multiple computers from a single PS/2 or USB KVM (keyboard, video, and mouse) console.

Aten CL5808N-ATA-AU 8 Port Rackmount Usb-ps/2 Dual Rail Slideaway, Resolutions: up to 1280 x 1024 @ 75 Hz, Operating temperature: 0 - 50 ° C, Non-operating temperature: -20 - 60 ° C, Operating humidity: 0 - 80 %, Depth: 480 mm, Width: 680.4 mm.   The CL5808N Slideaway Dual Rail LCD KVM Switch is a control unit that allows access to multiple computers from two PS/2 or USB KVM consoles.

Function: CL3116NX, Direct: 16, Maximum: 256 (via Cascade), Port Selection: OSD, Hotkey, Pushbutton, KVM Ports: 16 x SPHD Female (Yellow), Firmware Upgrade: 1 x 3.5mm Audio Jack Female (Black), Power: 1 x IEC 60320/C14, External Mouse Port: 1 x USB Type A Female (Front). The CL3116 can control up to 16 computers; when 16 additional KVM switches are cascaded, a single CL3116 LCD KVM Switch can control up to 256 computers. To achieve greater operational efficiency, the CL3116 offers Broadcast mode.

External Console Ports: 1 x HDMI Female, 2 x USB Type A Female, External Mouse / Peripheral: 1 x USB Type A Female (Front), Reset: 1 x Semi-recessed Pushbutton, Firmware Upgrade: 1 x Slide Switch, Power: 1 x Rocker Switch, LCD Control: 4 x Pushbutton, LCD Power: 1 x LED Pushbutton, Power: 1 x KVM Console (Dark Green), Power Consumption: AC110V:23.3W:124BTU. The CL3700NW-ATA-AU USB HDMI LCD Console is a short depth single rail LCD KVM console featuring an 18.5" LED-backlit widescreen LCD monitor with an integrated keyboard and touchpad.

Interfaces: 4 x RJ-45 Female (Silver), Impedance: 100, Power Consumption: 12.2W:57BTU, Operating Temperature: 0 - 40°C, Storage Temperature: -20 - 60°C.

Power Consumption: 16W:75BTU, Operating Temperature: 0–40°C, Storage Temperature: -20–60°C, Humidity: 0 - 80% RH, Non-Condensing, Housing: Metal, Weight: 0.60 kg ( 1.32 lb ).

Maximum: 256 (via Cascade), Port Selection: OSD, Hotkey, Pushbutton, RS-232Commands, Firmware Upgrade: 1 x RJ11 Female (Black), Power: 1 x DC Jack, USB Hub: 2 x USB3.1 Gen1 Type A Female (Blue; 2 x front), Port Selection: 16 x Pushbutton, Reset: 1 x Semi-recessed Pushbutton, Firmware Upgrade Recovery: 1 x Slide Switch, On Line /Selected: 16 (Orange), Power: 1 (Green), USB Link: 16 (Green), Keyboard / Mouse: USB, Power Consumption: DC12V:26.66W:175BTU, Housing: Metal, Warranty: 02 Years The ATEN CS19216 16-Port USB 3.0 4K DisplayPort KVM Switch can effectively access and control up to 16 DisplayPort computers

Interfaces: 4 x RJ-45 Female (Silver), Impedance: 100, Housing: Metal, Weight: 0.64 kg ( 1.41 lb ), Operating Temperature: 0 - 40°C, Storage Temperature: -20 - 60°C.

Maximum: 512 (via Daisy-chain), Port Selection: OSD, Hotkey, Pushbutton, KVM Ports: 16 x SPHD Female (Yellow), Daisy Chain Ports: 1 x DB-25 Male, Power: 1 x IEC 60320/C14, USB Port: 1 x USB Type A Female, Port Selection: 2 x Pushbutton, Reset: 1 x Semi-recessed Pushbutton, Power: 1 x Rocker Switch, LCD Control: 4 x Pushbutton, LCD Power: 1 x LED Pushbutton, Online: 16 (Orange), LCD Module: 17" TFT-LCD, Housing: Metal + Plastic, Rail Type: Single Rail, Warranty: 02 Years The CL5716 Slideaway™ LCD KVM Switch is a control unit that allows access to multiple computers from a single PS/2 or USB KVM (keyboard, video,

Interfaces: 4 x HDMI Type A Female (Black), Impedance: 100 , Max. Pixel Clock: 340 MHz, Operating Temperature: 0 - 40°C, Storage Temperature: -20 - 60°C, Humidity: 0 - 80% RH, Non-Condensing.

Operating Temperature: 0-40°C, Storage Temperature: -20-60°C, Humidity: 0-85% RH, Noncondensing, Housing: Metal, Rail Type: Dual Rail, Contrast Ratio: 1000:1, Luminance: 350 cd/m².
