ASRock H310M-ITX/ac Intel LGA1151 CL Mini-ITX Motherboard

SKU : H310M-ITX/AC
Brand : ASRock
Availablity : on order
On Order items usually have to be ordered in and may take bit longer to get them delivered from our Seven Hills, NSW warehouse
Asrock H310M-ITX/AC, LGA 1151 (300 Series), Turbo Boost Technology 2.0, Chipset Intel H310, 2×288pin, DDR4 2666/ 2400/ 2133, 32GB Dual Channel, 1 x Vertical M.2 Socket (Key E) with the bundled Wi-Fi 802.11 ac module (on the rear I/O), Intel I219-V, 10/100/1000Mbps, Supports Bluetooth 4.2 / 3.0 + High speed class II.   Intel LAN provides the best throughput performance, lower CPU utilization, enhanced stability and is able to deliver ultimate network experience to users!
Ask a question about this product
$153.00

Estimated Shipping

For Bulky items and non-metro Australia a different shipping will be quoted on order receipt.

No surcharge On Credit Card, AMEX or Paypal. American express, master card, nab, Paypal, visa

Share

  • Description
  • Specifications
  • Reviews

Product Description

Manufacture # Asrock | Model # H310M-ITX/AC



Intel LAN provides the best throughput performance, lower CPU utilization, enhanced stability and is able to deliver ultimate network experience to users.



Features:

  • Supports 9th and 8th Generation Intel Core Processors (Socket 1151)
  • Supports H310M-ITX/AC DDR4 2666
  • 1 PCIe 3.0 x16
  • Intel Gigabit LAN
  • Intel 802.11ac WiFi + BT 4.2



Overview:

  • PS/2: 1 x PS/2 keyboard/mouse port
  • Video Ports: 1 x DVI-I Port
  • HDMI: 1 x HDMI
  • RJ45: 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED)
  • DisplayPort: 1 x DisplayPort 1.2



Manufacturer Warranty: 03 Years Limited Warranty

Technical Specifications

General

Chipset A chipset is an electronic component in an integrated circuit known as a "Data Flow Management System" that manages the data flow between the processor, memory and peripherals.
Intel H310
Socket A CPU socket or CPU slot contains mechanical components providing mechanical and electrical connections between a processor and PCB. This allows for placing the CPU without soldering.
LGA1151
Supports 8th Generation Intel Core Processors
Supports CPU up to 95W
Digi Power design
5 Power Phase design
Supports Intel Turbo Boost 2.0 Technology
BIOS Basic Input/Output System, also known as the System BIOS is firmware used to provide runtime services for operating systems and programs to perform hardware initialization during the booting process.
128Mb AMI UEFI Legal BIOS with multilingual GUI support
ACPI 6.0 Compliant wake up events
SMBIOS 2.7 Support
CPU, DRAM, PCH 1.0V, VCCST Voltage Multi-adjustment
Unique Features
ASRock Super Alloy
Premium 60A Power Choke
Dual-Stack MOSFET (DSM)
Sapphire Black PCB
High Density Glass Fabric PCB

Memory

RAM Capacity The total memory that can be added to a computer depends on the address registers built into the CPU.
upto 64GB (32GB each)
DIMM Slots DIMM (dual in-line memory module) slots are the place on your motherboard where the RAM goes.
2
RAM Frequency Supports RAM frequency is measured in MHz and usually immediately follows the DDR version in the RAM spec.
DDR4 2666 / 2400 / 2133 non-ECC, un-buffered memory

Onboard Graphics

With HDMI
Supports HDMI with max. resolution up to 4K x 2K (4096x2160)@30Hz
With DisplayPort
Supports DisplayPort 1.2 with max. resolution up to 4K x 2K (4096x2304)@60Hz

Wireless Communication

Wi-Fi Wi-Fi is a wireless networking technology that allows devices such as computers, mobile devices, and other equipments to interface with the Internet.
Intel 802.11ac WiFi Module
Supports IEEE 802.11a/b/g/n/ac
Supports Dual-Band (2.4/5 GHz)
Supports high speed wireless connections up to 433Mbps
Bluetooth Bluetooth is a wireless technology that enables the exchange of data between devices using wavelength.
4.2 / 3.0 + High speed class II

Slots And Ports

Expansion Slots An expansion slot is a socket on the motherboard that is used to insert an expansion card, which provides additional features to a computer such as video, sound, graphics, ethernet or memory.
1 x PCI Express 3.0 x16 Slot (PCIE1: x16 mode)
1 x Vertical M.2 Socket (Key E) with the bundled WiFi-802.11ac PCIe WiFi module (on the rear I/O)
1 x M.2 Socket, supports M Key type 2280 M.2 SATA3 6.0 Gb/s module and M.2 PCI Express module up to Gen2 x4 (20 Gb/s)
Internal I/O Connectors An I/O (Input/Output) port is a socket on a computer that a cable is plugged into. The port connects the CPU to a peripheral device via a hardware interface or to the network via a network interface.
1 x Chassis Intrusion Header
1 x CPU Fan Connector (4-pin)
1 x Chassis/Water Pump Fan Connector (4-pin) (Smart Fan Speed Control)
1 x 24 pin ATX Power Connector
1 x 8 pin 12V Power Connector
1 x Front Panel Audio Connector
1 x USB 2.0 Header (Supports 2 USB 2.0 ports) (Supports ESD Protection)
1 x USB 3.1 Gen1 Header (Supports 2 USB 3.1 Gen1 ports) (Supports ESD Protection)
Back Panel Connectors The back or rear panel is the portion of the motherboard that allows you to connect external devices, such as your monitor, speakers, keyboard, mouse etc.
2 x Antenna Ports
1 x PS/2 Mouse/Keyboard Port
1 x DVI-I Port
1 x HDMI Port
1 x DisplayPort 1.2
2 x USB 2.0 Ports (Supports ESD Protection)
2 x USB 3.1 Gen1 Ports (Supports ESD Protection)
1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED)
HD Audio Jacks: Line in / Front Speaker / Microphone

Software

Operating System Supports An operating system (OS) is system software that manages computer hardware, software resources, and provides common services for computer programs.
Windows 11 64-bit
Windows 10 64-bit
Bundled Software
Software
- ASRock A-Tuning
- ASRock XFast LAN
UEFI
- ASRock EZ Mode
- ASRock Full HD UEFI
- ASRock My Favorites in UEFI
- ASRock Instant Flash
- ASRock Internet Flash

Physical

Form Factor The motherboard's form factor indicates the shape and size specifications of the board.
Mini-ITX
Dimensions
17cm x 17cm
