Name: Asus ROG STRIX B550-F GAMING WIFI II DDR4 AM4 ATX Motherboard
Brand: Asus
SKU: ROG STRIX B550-F GAMING WIFI II
Price: 298 AUD
Availability: InStock

Asus ROG STRIX B550-F GAMING WIFI II DDR4 AM4 ATX Motherboard

SKU : ROG STRIX B550-F GAMING WIFI II

Brand : Asus

Availablity : on order
On Order items usually have to be ordered in and may take bit longer to get them delivered from our Seven Hills, NSW warehouse

Estimated Shipping

Find

Description
Specifications
Reviews

Product Description

Manufacture # Asus | Model # ROG STRIX B550-F GAMING WIFI II

ROG Strix B550 Gaming series motherboards offer a feature-set usually found in the higher-end ROG Strix X570 Gaming series, including the latest PCIe 4.0. With robust power delivery and effective cooling, ROG Strix B550 Gaming is well-equipped to handle Zen 3 architecture AMD Ryzen CPUs. Boasting futuristic aesthetics and intuitive ROG software, ROG Strix B550-F Gaming WiFi II gives you a head start on your dream build.

Features:

ROG Strix B550-F Gaming WiFi II is PCIe 4.0-ready and provides the latest connectivity options for supersmooth networking and blisteringly fast file transfers.
Audio enhancements give you a massive advantage, allowing you to pick up on the subtlest of cues for a completely immersive gaming experience.
ROG Strix B550-F Gaming WiFi II features two M.2 slots, one of which supports the PCIe 4.0 standard to provide maximum storage flexibility and the lightning-fast data speeds. Both M.2 slots support up to the type 22110 socket and NVM Express RAID for a performance boost.
ROG Strix B550-F Gaming WiFi II provides robust power delivery to fuel Ryzen’s cores, comprehensive cooling, and support for faster memory - so it has everything you need to load up your build with high-performance components for playing in the big leagues.

Overview:

CPU: AMD Ryzen 5000 Series/ 5000 G-Series/ 4000 G-Series/ 3000 Series Desktop Processors
Socket: AM4
Chipset: B550
Memory: 4 x DIMM, Max. 128GB, DDR4
Memory Channel: Dual Channel
Storage: Supports 2 x M.2 slots and 6 x SATA 6Gb/s ports
Ethernet: 1 x Intel 2.5Gb Ethernet
Wireless: Wi-Fi 6E
Bluetooth: 5.2
BIOS: 256 Mb Flash ROM, UEFI AMI BIOS
Operating System: Windows 11 Ready
Form Factor: ATX

Manufacturer Warranty: 03 Years Limited Warranty

Technical Specifications

General

Chipset

AMD B550

Socket

AM4
AMD Ryzen 5000 Series/ 5000 G-Series/ 4000 G-Series/ 3000 Series Desktop Processors

BIOS

256 Mb Flash ROM, UEFI AMI BIOS

Unique Features

ASUS Q-Design
ASUS Thermal Solution
AURA Sync
ASUS EZ DIY

Memory

RAM Capacity

upto 128GB (32GB each)

DIMM Slots

RAM Frequency Supports

DDR4 5100(O.C) / 4866(O.C.) / 4600(O.C) / 4466(O.C.) / 4400(O.C) / 4266(O.C.) / 4133(O.C.) / 4000(O.C.) / 3866(O.C.) / 3600(O.C.) / 3466(O.C.) / 3200 / 3000 / 2800 / 2666 / 2400 / 2133 MHz, Un-buffered Memory

Onboard Graphics

With HDMI

1 x HDMI 2.1

With DisplayPort

1 x DisplayPort 1.2

Wireless Communication

Wi-Fi

2x2 Wi-Fi 6E (802.11 a/b/g/n/ac/ax)

Bluetooth

5.2

Slots And Ports

Expansion Slots

1 x PCIe 4.0 x16 SafeSlot (supports x16 mode)
1 x PCIe 3.0 x16 slot (supports x4 mode)
3 x PCIe 3.0 x1 slots
2 x M.2 slots and 6 x SATA 6Gb/s ports

Internal I/O Connectors

1 x 4-Pin AIO_Pump header
1 x 4-Pin CPU fan header
1 x 4-Pin CPU_OPT fan header
3 x 4-Pin Chassis fan headers
1 x 24-pin main power connector
1 x 8-pin +12V power connector
1 x 4-pin +12V power connector
2 x M.2 slots (Key M)
6 x SATA 6Gb/s ports
1 x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports
2 x USB 2.0 headers support additional 4 USB 2.0 ports
1 x Addressable Gen 2 header
2 x AURA RGB headers
1 x Clear CMOS header
1 x Front panel audio header (AAFP)
1 x 20-3 pin System Panel header with Chassis intrude function
1 x Thermal sensor header
1 x Thunderbolt header

Back Panel Connectors

2 x USB 3.2 Gen 2 ports (1 x Type-A + 1 x USB Type-C)
4 x USB 3.2 Gen 1 ports (4 x Type-A)
2 x USB 2.0 ports
1 x Wi-Fi Module
1 x DisplayPort
1 x HDMI port
1 x Intel I225-V 2.5G Ethernet
1 x Optical S/PDIF out
5 x Audio jacks
1 x BIOS FlashBack button
