Scanning Speed |
40 ppm |
Document Size - Multiple Sheets - Width |
50.8 mm to 215.9 mm |
Document Size - Multiple Sheets - Length |
50.8 mm to 355.6 mm |
Document Size - Single Sheet - Width |
50.8 mm to 215.9 mm |
Colour / Monochrome |
Yes / Yes |
2-Sided (Duplex) Scan |
Yes |
Colour Depth - Input |
48-bit colour processing |
Colour Depth - Output |
24-bit colour processing |
Resolution - Optical |
Up to 600 dpi × 600 dpi |
Resolution - Interpolated |
Up to 1,200 dpi × 1,200 dpi |
Document Scanning Width / Length |
Up to 215.9 mm |
Product Dimensions (W × D × H) |
299.5 mm × 190.5 mm × 215.9 mm |
Weight |
2.68 kg |
ADF (Automatic Document Feeder) |
Up to 60 sheets (20 lb / 80 g/m² A4/Letter size) |
Memory Capacity |
512 MB |
Warranty |
1 year Return to Base Warranty |
Contents |
Scanner, Quick Setup Guide, User's Guide, Network Guide, CD-ROMs, ADF Document Output Support, AC Adaptor, USB Cable |
Wireless Network Security |
WEP 64/128 bit, WPA-PSK (TKIP/AES), WPA2-PSK (AES), WPA3 |
Setup Support Utility |
WPS, WLAN Assistant |
Type |
Touchscreen LCD |
Size |
2.8 in. (71.1 mm) TFT colour LCD screen |
Power Source |
AC: 100-240 V, 50/60 Hz |
Power Consumption - Scanning |
Approx. 25W |
Power Consumption - Ready |
Approx. 7.3W |
Power Consumption - Power Saving / Deep Sleep |
Approx. 1.7W |
Power Consumption - Power OFF |
Approx. 0.1W |
Operating Temperature |
5°C to 35°C |
Operating Humidity |
20% to 80% |
Storage Humidity |
10% to 90% |
TWAIN Compliant - Windows® |
Windows Server 2012 / 2012 R2 / 2016 / 2019 |
TWAIN Compliant - Macintosh |
macOS v10.14.x / 10.15.x / 11.0.x / 11.1.x |
WIA Compliant - Windows® |
Windows 7 (SP1) / Windows 8.1 / Windows 10 |
ICA Compliant - Macintosh |
macOS v10.14.x / 10.15.x / 11.0.x / 11.1.x |
ISIS™ Compliant - Windows® |
Windows 7 (SP1) / Windows 8.1 / Windows 10 |
Included Software |
Windows: iPrint&Scan, ScanEssentials (Lite), PaperPort 14 SE, Kofax Power PDF, Presto! BizCard 6, Remote Setup
Mac: iPrint&Scan, Presto! BizCard 7, Remote Setup
Mobile: iPrint&Scan (iOS/Android) |
Mobile Apps |
Support Center, Mobile Connect |
