Functions |
Print |
Printer Type |
Laser Printer |
Product Dimensions (WxDxH) |
373 mm × 388 mm × 257 mm |
Weight |
9.5 kg |
Print Speed |
Up to 48 (A4) / Up to 50 (Letter) ppm |
Paper Type |
Plain Paper, Letterhead, Coloured Paper, Thin Paper, Thick Paper, Thicker Paper, Recycled Paper, Bond, Label, Envelope, Env. Thin, Env. Thick |
Paper Size |
A4, Letter, B5 (JIS), A5, A5 (Long Edge), A6, Executive, Legal, Mexico Legal, India Legal, Folio, 16K (195x270 mm), A4 Short (270mm Paper), COM-10, DL, C5, Monarch |
Maximum Paper Capacity |
Up to 1,390 sheets of 80 gsm plain paper (with Added Optional Trays) |
Resolution |
Up to 1200 x 1200 dpi |
2-Sided (Duplex) - Printing Paper Type |
Plain Paper, Letterhead, Coloured Paper, Thin Paper, Recycled Paper |
2-Sided (Duplex) - Paper Size |
A4, Letter, Legal, Mexico Legal, India Legal, Folio (Paper sizes other than A4 are supported only in some countries.) |
Tray #1 - Maximum Paper Weight |
60 to 163 gsm (16 to 43 lb) |
Tray #1 - Maximum Paper Capacity |
Up to 250 sheets of 80 gsm plain paper |
Tray #1 - Paper Size |
A4, Letter, B5 (JIS), A5, A5 (Long Edge), A6, Executive, Legal, Mexico Legal, India Legal, Folio, 16K (195x270 mm), A4 Short (270mm Paper) |
Tray #2 - Maximum Paper Weight |
60 to 120 gsm (16 to 32 lb) |
Tray #2 - Maximum Paper Capacity |
LT-5505: Up to 250 sheets of 80 gsm plain paper
LT-6505: Up to 520 sheets of 80 gsm plain paper |
Multi-purpose Tray - Maximum Paper Weight |
60 to 230 gsm (16 to 60 lb) |
Multi-purpose Tray - Paper Size |
Width: 69.8 to 215.9 mm (2.75" to 8.5")
Length: 127 to 355.6 mm (5" to 14")
Envelope: COM-10, DL, C5, Monarch |
Multi-purpose Tray - Maximum Paper Capacity |
Up to 100 sheets of 80 gsm plain paper |
Paper Output |
Up to 150 sheets of 80 gsm plain paper (face-down delivery to the face-down output paper tray)
1 sheet (face-up delivery to the face-up output tray) |
Connectivity |
Hi-Speed USB2.0, 10Base-T/100Base-TX/1000Base-T |
Display Type |
1 Line LCD (16 characters) |
Memory Capacity |
256 MB (For Australia)
512 MB (For Korea, Taiwan, and African countries)
1GB |
Power Source |
220 - 240 V AC 50/60 Hz |
Power Consumption - Printing |
Approximately 680 W (For Taiwan)
Approximately 670 W (Except for Taiwan) |
Power Consumption - Ready |
Approximately 31 W |
Power Consumption - Sleep |
Approximately 5.5 W |
Power Consumption - Power Off |
Approximately 0.05 W |
Noise Level |
54.0 dB (A) |
Supported OS |
Windows 10, Server 2012, Server 2012 R2, Server 2016, Server 2019 |
Mobile Apps |
Support Center, Print Service Plugin, Mobile Connect (31/01/2023) |
