Maximum label width (mm) |
62 |
Database upload from PC |
Yes |
Housing colour |
Glossy black and white |
Image upload from PC |
Yes |
Memory capacity |
6 MB |
Memory locations |
99 |
Technology |
Direct thermal |
Template upload from PC |
Yes |
Type |
DK rolls (DK die-cut labels / DK continuous length tape) |
AirPrint |
Yes |
USB interface |
Ver 2.0 (full speed) |
Wi-Fi Direct |
Yes |
Wirelesss network interface |
IEEE 802.11 b/g/n |
Dimensions |
125mm (W) x 234mm (D) x 145mm (H) |
Weight |
1.12 kg |
AC adaptor |
Yes |
AC adaptor power cord |
Yes |
Tape cassettes |
29mm x 90mm black print on white standard address labels (100 labels) - 62mm black/red print on continuous length paper tape (4 meters) |
USB cable |
Yes |
User guide |
Yes |
Warranty card |
Yes |
Quick setup guide |
Yes |
Wireless network security |
WEP, WPA-PSK/WPA2-PSK ?TKIP/AES), LEAP (CKIP), EAP-FAST (TKIP/AES), PEAP (TKIP/AES), EAP-TTLS (TKIP/AES), EAP-TLS (TKIP/AES) |
1 dimensional barcode symbologies |
CODE39, CODE128, UCC/EAN-128(GS1-128), ITF(I-2/5), CODABAR(NW-7), UPC-A, UPC-E, EAN13(JAN13), EAN8, GS1 DataBar(RSS)(GS1 DataBar Omnidirectional,GS1 DataBar Truncated,GS1 DataBar Stacked,GS1 DataBar Stacked Omnidirectional,GS1 DataBar Limited,GS1 DataBar Expanded,GS1 DataBar Expanded Stacked) |
2 dimensional barcode symbologies |
PDF417(Standard, Truncate, Micro), QR Code(Model 1, Model 2, Micro), Data Matrix (ECC200 Square, ECC200 Rectangular), MaxiCode, CODE93, POSTNET, UPC-E EXTENSION |
Black and red printing capability |
Yes |
Bitmap fonts |
Helsinki, Brussels, Letter Gothic Bold, San Diego, Brougham |
Maximum label width |
62 mm |
Maximum print width |
60.96 mm |
Outline/Vector fonts |
Helsinki, Brussels, Letter Gothic |
Resolution (dpi) |
300 x 300, 300 x 600 |
Standard print speed |
110 labels per minute |
Standard print speed |
176 mm per second |
Database file compatability |
csv, Microsoft Access, Microsoft Excel |
Date and time stamp |
Date and time |
Fonts |
All installed truetype fonts |
Frames |
126 |
Label orientations |
Horizontal, Vertical |
Microsoft Office add-in (highlight->click->print) |
Excel, Outlook, Word |
Screen capture |
Yes |
Sequential numbering |
1 - 9999 / A - Z / a - z |
Text alignment |
Centre, Justify, Left, Right |
Typestyles |
Bold, Horizontal lines, Invert, Italic, Normal, Shadow, Shadow light, Surround |
Vertical print |
Yes |
SDK (Software Development Kit) |
Yes |
