Mass |
Approx 2.0 kg (body only) |
Dimensions (W x H x D) |
146 x 142.5 x 229 mm (body without protrusions) |
Power Requirements |
DC 19.5V |
Battery Operating Time |
Approx. 54min. with BP-U35 battery |
Recording Format (Video) [XAVC Intra] |
XAVC-I QFHD 59.94p modevجº˜°VBR, MAX bit rate 600 Mbps, MPEG-4 AVC/H.264
XAVC-I QFHD 50p modevجº˜°VBR, MAX bit rate 500 Mbps, MPEG-4 AVC/H.264
XAVC-I QFHD 29.97p modevجº˜°VBR, MAX bit rate 300 Mbps, MPEG-4 AVC/H.264
XAVC-I QFHD 25p modevجº˜°VBR, MAX bit rate 250 Mbps, MPEG-4 AVC/H.264
XAVC-I QFHD 23.98p modevجº˜°VBR, MAX bit rate 240 Mbps, MPEG-4 AVC/H.264
XAVC-I HD 59.94p modevجº˜°CBG, MAX bit rate 222 Mbps, MPEG-4 AVC/H.264
XAVC-I HD 50p modevجº˜°CBG, MAX bit rate 223 Mbps, MPEG-4 AVC/H.264
XAVC-I HD 59.94i/29.97p modevجº˜°CBG, MAX bit rate 111 Mbps, MPEG-4 AVC/H.264
XAVC-I HD 50i/25p modevجº˜°CBG, MAX bit rate 112Mbps, MPEG-4 AVC/H.264
XAVC-I HD 23.98p modevجº˜°CBG, MAX bit rate 89Mbps, MPEG-4 AVC/H.264 |
Recording Format (Video) [MPEG-2 Long GOP] |
MPEG2 HD422 modevجº˜°CBR, MAX bit rate 50 Mbps, MPEG-2 422P@HL |
Recording Format (Audio) |
LPCM 24 bits, 48 kHz, 4 channels |
Lens Mount |
E-mount |
Imaging Device (Type) |
35 mm full-frame, single-chip CMOS image sensor |
Imaging Device (Pixel Count) |
20.5M pixels (Total) |
ISO Sensitivity |
ISO 800/4000 (Cine EI mode, D55 Light source) |
Built-in Optical Filters |
Clear, linear variable ND(1/4ND to 1/128ND) |
S/N Ratio |
57 dB (Y) (typical) |
Shutter Speed |
64F to 1/8000 sec |
Slow and Quick Motion Function |
FF 6K mode: XAVC-I/L. 3840 x 2160, 1920 x 1080, 1 to 30 frames (29.97/25/23.98) |
White Balance |
Preset, Memory A, Memory B (2000K-15000K)/ATW |
Gain |
-3 to 18dB (every 1dB), AGC |
Gamma Curve |
S-Cinetone, STD1, STD2, STD3, STD4, STD5, STD6, HG1, HG2, HG3, HG4, HG7, HG8, S-Log3 |
SDI Output |
SDI OUT1: BNC, 12G-SDI, 3G-SDI (Level A/B), HD-SDI, SDI OUT2: BNC, 3G-SDI (Level A/B), HD-SDI |
USB |
USB device, micro-B (x1) |
Headphone Output |
Stereo mini jack (x1) -16 dBu 16 O |
Speaker Output |
Monaural |
DC Input |
DC jack |
Remote |
Stereo mini-minijack (F2.5 mm) |
HDMI Output |
Type A (x1) |
LCD |
8.8 cm (3.5 type) Approx. 2.76M dots |
Supported Format |
IEEE 802.11 a/b/g/n/ac |
Frequency Band |
2.4 GHz bandwidth 5.2/5.3/5.6/5.8 GHz bandwidth |
Security |
WEP/WPA-PSK/WPA2-PSK |
NFC |
NFC Forum Type 3 Tag compliant |
