CISCO 40gbase-sr4 Qsfp Trnscvr Module Mpo Conn QSFP-40G-SR4-S

Name: CISCO 40gbase-sr4 Qsfp Trnscvr Module Mpo Conn QSFP-40G-SR4-S
Brand: Cisco
SKU: QSFP-40G-SR4-S
Price: 2395 AUD
Availability: InStock

SKU : QSFP-40G-SR4-S

Brand : Cisco

Availablity : on order
On Order items usually have to be ordered in and may take bit longer to get them delivered from our Seven Hills, NSW warehouse

Cisco QSFP-40G-SR4-S, Wavelength 850nm, Connector MTP/MPO, TX Power -7.6~1dBm, Power Consumption 1.2W, Max Data Rate 42Gbps, Powerbudget 3.5dB, Receiver Sensitivity<-11.1dBm, Extinction Ratio 3dB, Protocols 40G Ethernet, Infiniband QDR, SATA/SAS3, IEEE 802.3ba, MSA Compliant. The Cisco QSFP-40G-SR4-S Compatible QSFP+ Optical Transceiver Module is designed for use in 40GBASE Ethernet throughput up to 150m over OM4 multimode fiber (MMF) using a wavelength of 850nm via a MTP/MPO connector.

Ask a question about this product

$2,395.00

Buy Now

Estimated Shipping

Find

For Bulky items and non-metro Australia a different shipping will be quoted on order receipt.

No surcharge On Credit Card, AMEX or Paypal. American express, master card, nab, Paypal, visa

Description
Specifications
Reviews

Product Description

Manufacture # Cisco | Model # QSFP-40G-SR4-S

The Cisco QSFP-40G-SR4-S Compatible QSFP+ Optical Transceiver Module is designed for use in 40GBASE Ethernet throughput up to 150m over OM4 multimode fiber (MMF) using a wavelength of 850nm via a MTP/MPO connector.

Features:

It provides Cisco QSFP-40G-SR4-S high-density and low-power 40GBASE Ethernet solution for data centers
High-performance computing networks, enterprise core, distribution layers
It is fully compliant with the QSFP+ MSA and IEEE 802.3ba 40GBASE-SR4 and breakout to 4x10GBASE-SR standard.

Overview:

Cisco Compatible: QSFP-40G-SR4-S
Wavelength: 850nm
Connector: MTP/MPO
Transimitter Type: VCSEL 850nm
DDM/DOM: Supported
Power Consumption: 1.2W

Manufacturer Warranty: 01 Year Limited Warranty

Technical Specifications

Cisco Compatible	QSFP-40G-SR4-S
Form Factor	QSFP+
Wavelength	850nm
Connector	MTP/MPO
Transimitter Type	VCSEL 850nm
DDM/DOM	Supported
TX Power	-7.6~1dBm
Power Consumption	1.2W
Modulation Format	NRZ
Transmit and Dispersion Penalty	3.5dB
Packaging Technology	COB (chip on board) Packaging
Protocols	40G Ethernet Infiniband QDR SATA/SAS3 IEEE 802.3ba MSA Compliant
Max Data Rate	42Gbps
Max Cable Distance	150m@OM4 MMF
Media	MMF
Receiver Type	PIN
Commercial Temperature Range	0 to 70°C (32 to 158°F)
Receiver Sensitivity	<-11.1dBm
Extinction Ratio	3dB
CDR	None
Powerbudget	3.5dB
Application	40GBASE Ethernet Breakout to 4 x 10GBASE Ethernet Data Center
