Scanner Type |
ADF (Automatic Document Feeder) / Manual Feed, Duplex |
Scanning Speed (A4 Landscape)
(Color/Grayscale/Monochrome) |
Simplex : 60 ppm (200/300 dpi)
Duplex : 120 ipm (200/300 dpi) |
Scanning Speed (A4 Portrait)
(Color/Grayscale/Monochrome) |
Simplex : 50 ppm (200/300 dpi)
Duplex : 100 ipm (200/300 dpi) |
Image Sensor Type |
Color CCD x 2 (front x 1, back x 1) |
Light Source |
White LED Array x 4 (front x 2, back x 2) |
Optical Resolution |
600 dpi |
Output Resolution
(Color / Grayscale / Monochrome) |
50 to 600 dpi (adjustable by 1 dpi increments), 1,200 dpi (driver) |
Output Format |
Color: 24-bit, Grayscale: 8-bit, Monochrome: 1-bit |
Background Colors |
White / Black (selectable) |
Document Size |
Maximum : 304.8 x 431.8 mm (12 x 17 in.)
Minimum : 50.8 x 69 mm (2 x 2.7 in.) (Portrait)
Long Page Scanning : 5,588 mm (220 in.) |
Paper Weight (Thickness) |
Paper
27 to 413 g/m2 (7.2 to 110 lb)
A8 size : 127 to 209 g/m2 (34 to 56 lb)
Plastic Card : Up to 1.4 mm |
ADF Capacity |
100 sheets (A4 80 g/m2 or Letter 20 lb) |
Expected Daily Volume |
18,000 sheets |
Multifeed Detection |
Overlap detection (Ultrasonic sensor), Length detection |
Paper Protection |
Lag detection, Sound detection (iSOP) |
Interface |
USB 3.0 / USB 2.0 / USB 1.1 |
Power Requirements |
AC 100 to 240 V ±10 % |
Power Consumption |
Operating Mode : 36 W or less
Sleep Mode : 1.4 W or less
Auto Standby (Off) Mode : 0.35 W or less |
Operating Environment |
Temperature : 5 to 35 °C (41 to 95 °F
Relative Humidity : 20 to 80% (non-condensing) |
Environmental Compliance |
ENERGY STAR, RoHS |
Dimensions (W x D x H) |
380 x 209 x 168 mm (15.0 x 8.2 x 6.6 in.) |
Weight |
7.6 kg (16 lb) |
Supported Operating System |
Windows 10 (12), Windows 8.1, Windows 7, Windows Server 2019, Windows Server 2016, Windows Server 2012 R2, Windows Server 2012, Windows Server 2008 R2, Windows Server 2008 (13), Linux (Ubuntu) (14)(15) |
Included Software / Drivers |
PaperStream IP Driver (TWAIN/TWAIN x64/ISIS), WIA Driver (14), PaperStream Capture, ScanSnap Manager for fi Series (15), Software Operation Panel, Error Recovery Guide, ABBYY FineReader for ScanSnap™ (15), Scanner Central Admin, 2D Barcode for PaperStream (15) |
Image Processing Functions |
Multi image output, Automatic color detection, Blank page detection, Dynamic threshold (iDTC), Advanced DTC, SDTC, Error diffusion, Dither, De-Screen, Emphasis, Dropout color (None/Red/Green/Blue/White/Saturation/Custom), sRGB output, Hole punch removal, Index tab cropping, Split image, De-Skew, Edge correction, Vertical streaks reduction, Cropping, Static threshold |
Included Items |
ADF paper chute, AC cable, AC adapter, USB cable, Setup DVD-ROM |
