Image Sensor |
1/1.8" Progressive Scan CMOS |
Max. Resolution |
3840 × 2160 |
Min. Illumination |
Color: 0.003 Lux @ (F1.6, AGC ON), B/W: 0 Lux with IR |
Shutter Time |
1/3 s to 1/100,000 s |
Day & Night |
IR cut filter |
Angle Adjustment |
Pan: 0° to 355°, tilt: 0° to 75°, rotate: 0° to 355° |
Lens Type |
Fixed focal lens, 2.8 and 4 mm optional |
Focal Length & FOV |
2.8 mm, horizontal FOV 111°, vertical FOV 59°, diagonal FOV 131%
4 mm, horizontal FOV 87°, vertical FOV 47°, diagonal FOV 102° |
Lens Mount |
M12 |
Iris Type |
Fixed |
Aperture |
F1.6 |
DORI (2.8 mm) |
D: 89.2 m, O: 35.4 m, R: 17.8 m, I: 8.9 m |
DORI (4 mm) |
D: 99.4 m, O: 39.4 m, R: 19.9 m, I: 9.9 m |
Supplement Light Type |
IR |
Supplement Light Range |
Up to 30 m |
Smart Supplement Light |
Yes |
IR Wavelength |
850 nm |
Main Stream |
50 Hz: 25 fps (3840 × 2160, 3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)
60 Hz: 24 fps (3840 × 2160)
30 fps (3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720) |
Sub-Stream |
50 Hz: 25 fps (640 × 480, 640 × 360)
60 Hz: 30 fps (640 × 480, 640 × 360) |
Third Stream |
50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360) |
Video Compression |
Main stream: H.265/H.264/H.264+/H.265+
Sub-stream: H.265/H.264/MJPEG
Third stream: H.265/H.264 |
Video Bit Rate |
32 Kbps to 16 Mbps |
H.264 Type |
Baseline Profile/Main Profile/High Profile |
H.265 Type |
Main Profile |
Bit Rate Control |
CBR/VBR |
Region of Interest (ROI) |
1 fixed region for main stream and sub-stream |
Target Cropping |
Yes |
Audio Type |
-U: mono sound |
Audio Compression |
-U: G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/MP3/AAC |
Audio Bit Rate |
-U: 64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)/16 to 64 Kbps (AAC) |
Audio Sampling Rate |
-U: 8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz |
Environment Noise Filtering |
-U: Yes |
Protocols |
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, ARP |
Simultaneous Live View |
Up to 6 channels |
API |
Open Network Video Interface (PROFILE S, PROFILE G, PROFILE T), ISAPI, SDK |
User/Host |
Up to 32 users. 3 user levels: administrator, operator, and user |
Security |
Password protection, complicated password, HTTPS encryption, IP address filter, Security Audit Log, basic and digest authentication for HTTP/HTTPS, TLS 1.1/1.2, WSSE and digest authentication for Open Network Video Interface |
Network Storage |
MicroSD/SDHC/SDXC card (256 GB) local storage, and NAS (NFS, SMB/CIFS), auto network replenishment (ANR) |
Client |
iVMS-4200, Hik-Connect, Hik-Central |
Web Browser |
Plug-in required live view: IE 10+
Plug-in free live view: Chrome 57.0+, Firefox 52.0+
Local service: Chrome 57.0+, Firefox 52.0+ |
Image Parameters Switch |
Yes |
Image Settings |
Rotate mode, saturation, brightness, contrast, sharpness, gain, white balance adjustable by client software or web browser |
Day/Night Switch |
Day, Night, Auto, Schedule |
Wide Dynamic Range (WDR) |
120 dB |
SNR |
≥ 52 dB |
Image Enhancement |
BLC, HLC, 3D DNR |
Ethernet Interface |
1 RJ45 10 M/100 M self-adaptive Ethernet port |
On-Board Storage |
Built-in memory card slot, support microSD/SDHC/SDXC card, up to 256 GB |
Built-in Microphone |
-U: Yes |
Audio Input/Output |
1 input (line in), max. input amplitude: 3.3 vpp, input impedance:4.7 KΩ, interface type: non-equilibrium; 1 output (line out), max. output amplitude: 3.3 vpp, output impedance: 100 Ω, interface type: non-equilibrium, mono sound |
Alarm |
-S: 1 input, 1 output (TTL: max. 12 VDC, 30 mA) |
Reset Key |
Yes |
Event |
Basic Event: Motion detection (human and vehicle targets classification), video tampering alarm, exception
Smart Event: Scene change detection |
Linkage |
Upload to FTP/memory card/NAS, notify surveillance center, send email, trigger recording, trigger capture |
Face Capture |
Yes |
Power |
12 VDC ± 25%, 0.5 A, max. 6 W, Ø5.5 mm coaxial power plug
PoE: 802.3af, Class 3, 36 V to 57 V, 0.25 A to 0.15 A, max. 7.5 W |
Dimensions |
Ø121.4 mm × 92.2 mm (Ø4.8" × 3.6") |
Package Dimensions |
150 mm × 150 mm × 141 mm (5.9" × 5.9" × 5.6") |
Weight |
Approx. 590 g (1.3 lb.) |
With Package Weight |
Approx. 850 g (1.9 lb.) |
Storage Conditions |
-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) |
Startup and Operating Conditions |
-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) |
Language |
33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian |
General Functions |
Anti-flicker, heartbeat, mirror, privacy mask, flash log, password reset via email, pixel counter |
Approval |
EMC: FCC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014); RCM (AS/NZS CISPR 32: 2015); KC (KN 32: 2015, KN 35: 2015) |
Safety |
UL (UL 60950-1); CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013, IEC 62368-1:2014); CE-LVD (EN 60950-1:2005 + Am 1:2009 + Am 2:2013, IEC 62368-1:2014) |
Environment |
CE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006) |
Protection |
IP67 (IEC 60529-2013), IK10 (IEC 62262:2002) |
