Image Sensor |
1/3" Progressive Scan CMOS |
Max. Resolution |
2688 × 1520 |
Min. Illumination |
Color: 0.005 Lux @ (F1.6, AGC ON) |
Shutter Time |
1/3 s to 1/100,000 s |
Angle Adjustment |
Tilt: 0° to 75° |
Focal Length & FOV |
2.8 mm: Horizontal FOV 103°, Vertical FOV 55°, Diagonal FOV 122°
4 mm: Horizontal FOV 84°, Vertical FOV 43°, Diagonal FOV 100° |
Aperture |
F1.6 |
Lens Mount |
M12 |
DORI Distance |
2.8 mm: Detect: 56 m, Observe: 22 m, Recognize: 11 m, Identify: 6 m
4 mm: Detect: 85 m, Observe: 34 m, Recognize: 17 m, Identify: 9 m |
Main Stream |
50 Hz: 25 fps (2688 × 1520, 1920 × 1080, 1280 × 720)
60 Hz: 30 fps (2688 × 1520, 1920 × 1080, 1280 × 720) |
Sub-Stream |
50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360)
60 Hz: 30 fps (1280 × 720, 640 × 480, 640 × 360) |
Third Stream |
50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360) |
Video Compression |
Main stream: H.265/H.264/H.264+/H.265+
Sub-stream: H.265/H.264/MJPEG
Third stream: H.265/H.264 |
Video Bit Rate |
32 Kbps to 8 Mbps |
H.264 Type |
Baseline Profile/Main Profile/High Profile |
H.265 Type |
Main Profile |
Bit Rate Control |
CBR/VBR |
Scalable Video Coding (SVC) |
H.264 and H.265 encoding |
Region of Interest (ROI) |
1 fixed region for main stream and sub-stream |
Environment Noise Filtering |
Yes |
Audio Sampling Rate |
8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz |
Audio Compression |
G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC |
Audio Bit Rate |
64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/16 to 64 Kbps (AAC-LC)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3) |
Simultaneous Live View |
Up to 6 channels |
API |
ONVIF (Profile S, Profile G), ISAPI, SDK, ISUP |
Protocols |
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, WebSocket, WebSockets |
User/Host |
Up to 32 users, 3 levels: administrator, operator, and user |
Security |
Password protection, HTTPS encryption, IP address filter, Security Audit Log, TLS 1.1/1.2, WSSE and digest authentication |
Network Storage |
NAS (NFS, SMB/CIFS), ANR with Hikvision memory card encryption and health detection |
Client |
iVMS-4200, Hik-Connect, Hik-Central |
Web Browser |
IE 10, IE 11 (Plug-in required)
Chrome 57.0+, Firefox 52.0+, Edge 89+ (Plug-in free) |
Wide Dynamic Range (WDR) |
120 dB |
Privacy Mask |
4 programmable polygon privacy masks |
Day/Night Switch |
Day, Night, Auto, Schedule |
Image Enhancement |
BLC, HLC, 3D DNR |
Image Parameters Switch |
Yes |
Image Settings |
Rotate mode, saturation, brightness, contrast, sharpness, gain, white balance adjustable via client software or web browser |
