Intel Xeon Gold 6252 Processor 35.75m Cache 2.10 Ghz 24 Cores 48 Threa (BX806956252)

SKU : BX806956252
Brand : Intel
Availablity : on order
On Order items usually have to be ordered in and may take bit longer to get them delivered from our Seven Hills, NSW warehouse
Lenovo Thinksystem Intel Xeon Gold BX806956252, CPU Socket Type LGA 3647, 24-Core Threads 48, Operating Frequency 2.1 GHz, Max Turbo Frequency 3.7 GHz, 6 Channel, PCI Express Revision 3.0, Cooling device not included - Processor Only, Thermal Design Power 150W.   Boost the functionality of your system with the Intel Xeon Gold 6252 Processor. This Intel Xeon processor offers a clock speed of 2.1 GHz for ultra-fast performance. With 24 cores and 48 threads, this processor supports multiprocessing and maintains.
Ask a question about this product
$8,398.00

Estimated Shipping

For Bulky items and non-metro Australia a different shipping will be quoted on order receipt.

No surcharge On Credit Card, AMEX or Paypal. American express, master card, nab, Paypal, visa

Share

  • Description
  • Specifications
  • Reviews

Product Description

Manufacture # Intel | Model # BX806956252



Boost the functionality of your system with the Intel Xeon Gold 6252 Processor. This Intel Xeon processor offers a clock speed of 2.1 GHz for ultra-fast performance. With 24 cores and 48 threads, this processor supports multiprocessing and maintains correct program state efficiently and reliability. It facilitates quick loading of programs and quick access of frequently used data from the main memory.



Features:

  • BX806956252 Virtualization Technology for Directed I/O (VT-d), Intel Optane Memory Supported, Intel TSX-NI, Intel 64 Technology
  • Intel VT-x with Extended Page Tables (EPT), Intel Trusted Execution Technology
  • Intel Resource Director Technology (RDT), BX806956252 Deep Learning Boost (DL Boost)
  • Intel Run Sure Technology, Intel Turbo Boost Technology 2.0, Enhanced SpeedStep technology
  • Intel AES New Instructions (AES-NI), Execute Disable Bit capability
  • Intel Volume Management Device (VMD), Intel Advanced Vector Extensions 512 (AVX-512)
  • BX806956252 Virtualization Technology, Hyper-Threading Technology
  • Intel vPro Technology, Mode-based Execute Control (MBE), Intel Speed Shift Technology.



Overview:

  • Operating Frequency: 2.1 GHz
  • Max Turbo Frequency: 3.7 GHz
  • L3 Cache: 36MB
  • Manufacturing Tech: 14 nm
  • 64-Bit Support: Yes
  • Hyper-Threading Support: Yes
  • Memory Channel: 6 Channel
  • PCI Express Revision: 3.0
  • Max # of PCI Express Lanes: 48





Manufacturer Warranty: 03 Years Limited Warranty

Technical Specifications

General

Series/Family
2nd Generation Intel Xeon
Supported Socket The socket is the component that provides the mechanical and electrical connections between the processor and motherboard.
LGA3647
Total Cores Cores is a hardware term that describes the number of independent central processing units in a single computing component (die or chip).
24
No. of Performance-cores
N/A
No. of Efficient-cores
N/A
Total Threads Threads are the virtual components, which divides the physical core of a CPU into virtual multiple cores.
48
Max Turbo/Boost Clock Max Turbo/Boost Clock Frequency is the maximum single-core frequency at which the processor is capable of operating.
3.70GHz
Base Clock
2.10GHz
Cache CPU Cache is an area of fast memory located on the processor. Cache refers to the architecture that allows all cores to dynamically share access to the last level cache.
L3: 35.75MB
Default TDP
150W
Lithography Lithography refers to the semiconductor technology used to manufacture an integrated circuit, and is reported in nanometer (nm), indicative of the size of features built on the semiconductor.
14nm
Segment
Server

Connectivity

PCI Express Version Peripheral Component Interconnect Express (or PCIe) is a high-speed serial computer expansion bus standard for attaching hardware devices to a computer. The different PCI Express versions support different data rates.
3.0
Memory Types
DDR4 up to 2933 MHz

Additional Info

Integrated Graphics Integrated Graphics indicates graphics processing circuitry integrated into the processor, providing the graphics, compute, media, and display capabilities.
No
Supported Chipset
C621, C622
Code Name
Cascade Lake
