PERFORMANCE
Processor
Intel® Core™ i7-1355U, 10C (2P + 8E) / 12T, P-core 1.7 / 5.0GHz, E-core 1.2 / 3.7GHz, 12MB
Graphics
Intel Iris Xe Graphics capability requires system to be configured with dual-channel memory. On the system with single-channel memory, Intel Iris Xe Graphics will function as Intel UHD Graphics.
Integrated Intel® Iris® Xe Graphics Functions as UHD Graphics
Chipset
Intel® SoC Platform
Memory
Installed memory is actually DDR5-5600 but run as DDR5-5200 due to platform limitation.
16GB Soldered DDR5-5200
Memory Slots
Models with DDR5 memory: one memory soldered to systemboard, one DDR5 SO-DIMM slot, dual-channel capable
Max Memory
The max memory is based on the test results with current Lenovo memory offerings.
Models with DDR5 memory: up to 32GB (16GB soldered + 16GB SO-DIMM) DDR5-5200
Storage
512GB SSD M.2 2280 PCIe® 4.0x4 NVMe® Opal 2.0
Storage Support
The storage capacity supported is based on the test results with current Lenovo storage offerings.
One drive, up to 2TB M.2 2280 SSD
Storage Slot
One M.2 2280 PCIe® 4.0 x4 slot
Card Reader
None
Optical
None
Audio Chip
High Definition (HD) Audio, Realtek® ALC3287 codec
Speakers
Stereo speakers, 2W x2, Dolby Audio™
Camera
FHD 1080p + IR Hybrid with Privacy Shutter
Microphone
2x, 360°
Battery
Integrated 52.5Wh
Power Adapter
65W USB-C® (3-pin)
DESIGN
Display
IPS (in-plane switching) technology may refer to IPS, PLS, ADS, AHVA, AAS.
14" WUXGA (1920x1200) IPS 300nits Anti-glare, 45% NTSC, Touch
Touchscreen
On-cell, 10-point Multi-touch
Keyboard
Backlit, English
Case Color
Thunder Black
Case Material
Carbon Fiber Hybrid (Top), PPS (Bottom)
Pen
Pen Not Supported
Dimensions (WxDxH)
The system dimensions may vary depending on configurations.
317.7 x 226.9 x 17.9 mm (12.51 x 8.93 x 0.70 inches)
Weight
The system weight is approximate and based on results in Lenovo lab, which varies depending on the source of component, variance of the distribution of each component, and manufacturing process. It may not be the exact weight for each specific model.
Starting at 1.37 kg (3.01 lbs)
SOFTWARE
Operating System
Windows® 11 Pro, English
Bundled Software
None
CONNECTIVITY
Ethernet
100/1000M (RJ-45)
WLAN + Bluetooth
Intel® Wi-Fi® 6E AX211, 802.11ax 2x2 + BT5.3
WWAN
Non-WWAN
SIM Card
None
NFC
None
Standard Ports
1x USB 3.2 Gen 1
1x USB 3.2 Gen 1 (Always On)
2x Thunderbolt™ 4 / USB4® 40Gbps (support data transfer, Power Delivery 3.0 and DisplayPort™ 1.4)
1x HDMI® 2.1, up to 4K/60Hz
1x Headphone / microphone combo jack (3.5mm)
1x Ethernet (RJ-45)
Optional Ports (configured)
None
Docking
Various docking solutions supported via Thunderbolt™ / USB-C®. For more compatible docking solutions
SECURITY & PRIVACY
Smart Card Reader
None
Security Chip
Discrete TPM 2.0 Enabled
Fingerprint Reader
Touch Style, Match-on-Chip, Integrated in Power Button
Physical Locks
Kensington® Nano Security Slot™, 2.5 x 6 mm
Other Security
Camera privacy shutter (camera models)
IR camera for Windows® Hello (facial recognition)
Glance by Mirametrix®
Ultrasonic Human Presence Detection (IR camera models)
MANAGEABILITY
System Management
Non-vPro®
SERVICE
Base Warranty
1-year, Courier or Carry-in
Included Upgrade
3Y Onsite upgrade from 1Y Courier/Carry-in, 1Y Premier Support Upgrade from 1Y Courier/Carry-in, CO2 Offset 0.5 ton
ACCESSORIES
Bundled Accessories
None
CERTIFICATIONS
Green Certifications
EPEAT is registered where applicable, please visit
epeat.net for registration status by country.
ENERGY STAR® 8.0
EPEAT™ Gold Registered
ErP Lot 6/26
RoHS compliant
TCO Certified 9.0
Mil-Spec Test
MIL-STD-810H military test passed
