Panel :- |
|
Screen Size |
55" |
Panel Technology |
U-IPS |
Native Resolution |
3,840 x 2,160 (UHD) |
Brightness (Typ.) |
450 nit |
Contrast Ratio |
1,000 :1 |
Color gamut |
NTSC 72% |
Viewing Angle (H x V) |
178 x 178 |
Color Depth |
1.07 Billion Colours (10 bit) |
Response Time |
9ms |
Operation Hours (Hours / Days) |
24/7 |
Portrait / Landscape |
Landscape |
Mechanical Specification :- |
|
Bezel Color |
Silver |
Bezel Width |
57.2/ 26.2/ 26.2/ 28.9mm ( T/ R /L /B) |
Weight (Head) |
26kg |
Monitor Dimensions (W × H × D) |
1265 x 769.5 x 61.8 mm |
VESA Standard Mount Interface |
300 x 300 |
Monitor Dimensions with Stand (W × H × D) |
1265 x 815 x 290 mm |
Touch |
Max 10 Points, Windows 10 or higher |
Connectivity :- |
|
Input |
HDMI (2), USB Type C(1)
USB3.1 Type A(2), (LAN) In |
Output |
DP Out : USB Type-C (DP ALT MODE) |
External Control |
IR |
Key Feature(Hardware) :- |
|
PC |
Windows 10 IOT Enterprise (Value), CPU: AMD Ryzen Embedded V1605B; GPU:AMD Radeon Vega, 128GB SSD, 8GB Ram, Wi-FI(802.11ac 2x2), Bluetooth 5.0, Launcher Bar, SplitView(Full/Half), Cloning, Screen Capture, Meeting(Voice) Record, File Sharing, MS Whiteboard, One:Quick Share, One:Quick Remote Meeting |
Camera |
3,840 x 2,160 (UHD) ,120° FoV, 4 x Zoom ,Video Framing |
MIC |
10EA, Beamforming |
Panel |
WebOS 4.1, Temperature Sensor, Auto Brightness Sensor, Local Key Operation, 2 x10W Speaker |
Environment Conditions :- |
|
Operation Temperature |
0°C to 40°C |
Operation Humidity |
10% to 80% |
Power :- |
|
Power Supply |
AC 100–240 V ~, 50/60 Hz |
Power Type |
Built-In Power |
Power Consumption (Typ. / Max.) |
195W / 275W |
Power Consumption - BTU (British Thermal Unit) |
81 BTU/Hr (Typ.) |
Sound :- |
|
Speaker |
10W x 2 |
Certification :- |
|
Safety |
AS/NZS 60950,CB Scheme |
EMC |
CISPR 32 |
Media Player Compatibility :- |
|
OPS Type Compatible |
No |
OPS Power Built In |
No |
Software Compatibility :- |
|
Software Compatibility |
SuperSign CMS, SuperSign Control / Control+, LG ConnectedCare |
Accessories :- |
|
Basic |
Remote Controller(include battery 2ea), Power Cord, Touch Pen, Pen tip, Manual, Specification book, Warranty Card, Installation Guide |
Optional |
2 pole Stand (ST-653TW) |
