Panel :- |
|
Screen Size |
43" |
Panel Technology |
IPS |
Back Light Type |
Edge |
Aspect Ratio |
16:9 |
Native Resolution |
3,840 X 2,160 (UHD) |
Refresh Rate |
60 Hz |
Brightness (Typ.) |
500 nit |
Contrast Ratio |
1,000 : 1 |
Dynamic CR |
1,000,000 : 1 |
Color gamut |
BT709 95% |
Viewing Angle (H x V) |
178 x 178 |
Color Depth |
10bit(D), 1.07Billion colors |
Response Time |
Tr : 8ms / Tf :10ms |
Surface Treatment (Haze) |
28% |
Life Time (Min.) |
50,000 Hrs |
Operation Hours (Hours / Days) |
24 / 7 |
Portrait / Landscape |
Yes / Yes |
Mechanical Specification :- |
|
Bezel Color |
Black |
Bezel Width |
8.9 mm (T/R/L), 12.9 mm (B) |
Weight (Head) |
11.1 kg |
Monitor Dimensions (W × H × D) |
963 x 556.2 x 29.7mm (without IR) |
Handle |
No |
VESA Standard Mount Interface |
200 x 200 mm |
Key Feature |
Internal Memory 16 GB, Built-in Wi-Fi, Sensor (Temperature Sensor, Auto Brightness Sensor (External IR), Acceleration (Gyro) Sensor), Local Key Operation, Built-in Speaker, webOS 6.0, Local Contents Scheduling, Group Manager, USB Plug & Play, Fail Over, Image (Booting Logo Image, No Signal Image), Sync (RS-232C Sync, Local Network Sync), PIP, PBP (4), Screen Share, Video Tag (4), Play via URL, Rotation (Screen Rotation, External Input Rotation), Gapless Playback, Tile Mode Setting (Max. 15 × 15), Setting Data Cloning, SNMP, ISM Method, Auto Set ID, Status Mailing, Control Manager, 3rd Party Compatibility (Cisco Certi, Crestron Connected®), Smart Energy Saving, PM Mode, Wake on LAN, Network Ready, Beacon, HDMI-CEC, SI Server Setting, webRTC, Pro:Idiom |
Environment Conditions :- |
|
Operation Temperature |
0 °C to 40 °C |
Operation Humidity |
10 % to 80 % |
Power :- |
|
Power Supply |
AC 100-240 V ~, 50/60 Hz |
Power Type |
Built-In Power |
Power Consumption :- |
|
Typ./Max. |
80W / 120W |
Smart Energy Saving (70%) |
56W |
DPM |
0.5W |
Power off |
0.5W |
BTU (British Thermal Unit) |
273 BTU/Hr(Typ.), 409 BTU/Hr(Max) |
Certification :- |
|
Safety |
CB / NRTL |
EMC |
FCC Class “B" / CE / KC |
ePEAT (US Only) |
Yes |
ErP / Energy Star |
Yes (NewErP) / Yes |
ISTA6 |
Yes (~Sep. 23y, US Suffix Only) |
Carbon Trust |
Yes (CO2 Reducing (TBD)) |
OPS Compatibility :- |
|
OPS Type Compatible |
No |
OPS Power Built In |
No |
Software Compatibility |
SuperSign CMS, SuperSign Control / Control+, SuperSign WB, SuperSign Cloud, Mobile CMS, LG ConnectedCare |
Connectivity :- |
|
Input |
HDMI In (3, 3,840 × 2,160 @ 60Hz, HDCP 2.2/1.4), DP In (3,840 × 2,160 @ 60Hz, HDCP 2.2/1.3), RS-232C In (4 Pin Phone-jack), RJ45 (LAN) In, IR In, USB In 2.0 (Type A) |
Output |
HDMI Out (3,840 × 2,160 @ 30Hz, Input (HDMI1/2/3/DP)), Audio Out, RS-232C Out (4 Pin Phone-jack), Daisy Chain (Input HDMI, DP / Output HDMI) |
Language |
English, French, German, Spanish, Italian, Korean , Chinese(Simplified), Chinese(Original), Portugues(Brazil), Swedish, Finnish, Norwegian, Danish, Russian, Japanese, Portugues(Europe), Dutch, Czech, Greek, Türkiye, Arabic |
Accessory :- |
|
Basic |
Remote Controller(include battery 2ea), Power Cord, QSG, Regulation Book, Phone to RS232C Gender, Cable Holder(2EA), AC Cord Holder (1EA) |
Optional |
Slim Wall Mount (WB21LMA/B), Wall Mount (LSW240A/B) Wall Mount Adapter (AM-B220S) |
Special Feature :- |
|
Tilt (Facedown) |
Yes (Max 30º degree, 40ºC temperature) |
IP Rating |
IP5X |
Conformal Coating (Power Board) |
Yes |
