Panel |
|
Screen Size |
49" |
Panel Technology |
IPS |
Back Light Type |
Edge |
Aspect Ratio |
16:9 |
Native Resolution |
3,840 x 2,160 (4K UHD) |
Refresh Rate |
60 Hz |
Brightness (Typ.) |
700 nit |
Contrast Ratio |
1,100:1 |
Dynamic CR |
1,000,000 : 1 |
Color Gamut |
BT709 95% |
Viewing Angle (H x V) |
178 × 178 |
Color Depth |
1.07 Billion Colors (10 bit (D)) |
Response Time |
8ms (G to G) |
Surface Treatment (Haze) |
28% |
Life Time (Min.) |
50,000 Hrs |
Operation Hours (Hours / Days) |
24 / 7 |
Portrait / Landscape |
Yes / Yes |
Mechanical Specification |
|
Bezel Color |
Black |
Bezel Width |
8.9 mm (T/R/L), 12.9 mm (B) |
Weight (Head) |
13.6 kg |
Packed Weight |
16.1 kg |
Monitor Dimensions (W × H × D) |
1,095.6 x 630.8 x 29.7 mm (without IR) |
Carton Dimensions (W × H × D) |
1,215 x 736 x 152 mm |
Handle |
No |
VESA™ Standard Mount Interface |
300 × 300 mm |
Key Features |
|
Internal Memory |
16 GB |
Built-in Wi-Fi |
Yes |
Sensors |
Temperature, Auto Brightness, Gyro |
Local Key Operation |
Yes |
Built-in Speaker |
10W x 2 |
Operating System |
webOS 6.0 |
Local Contents Scheduling |
Yes |
Group Manager |
Yes |
USB Plug & Play |
Yes |
Fail Over |
Yes |
Image |
Booting Logo, No Signal Image |
Sync |
RS-232C Sync, Local Network Sync |
PIP |
Yes |
PBP |
4 |
Screen Share |
Yes |
Video Tag |
4 |
Play via URL |
Yes |
Rotation |
Screen Rotation, External Input Rotation |
Gapless Playback |
Yes |
Tile Mode Setting |
Max. 15 × 15 |
Setting Data Cloning |
Yes |
SNMP |
Yes |
ISM Method |
Yes |
Auto Set ID |
Yes |
Status Mailing |
Yes |
Control Manager |
Yes |
3rd Party Compatibility |
Cisco Certification (TBD), Crestron Connected® |
Smart Energy Saving |
Yes |
PM Mode |
Yes |
Wake on LAN |
Yes |
Network Ready |
Yes |
Beacon |
Yes |
HDMI-CEC |
Yes |
SI Server Setting |
Yes |
webRTC |
Yes |
Pro
|
Yes |
Environment Conditions |
|
Operation Temperature |
0 °C to 40 °C |
Operation Humidity |
10 % to 80 % |
Power |
|
Power Supply |
AC 100-240 V ~, 50/60 Hz |
Power Type |
Built-In Power |
Power Consumption |
|
Typ./Max. |
90 W / 130 W |
Smart Energy Saving (70%) |
63 W |
DPM |
0.5 W |
Power off |
0.5 W |
Certification |
|
Safety |
CB / NRTL |
EMC |
FCC Class “B" / CE / KC |
ePEAT (US Only) |
Yes |
ErP / Energy Star |
Yes (NewErP) / Yes |
ISTA6 |
Yes (~'23.9, US Suffix Only) |
Carbon Trust |
Yes (CO2 Measured (TBD)) |
OPS Compatibility |
|
OPS Type Compatible |
No |
OPS Power Built In |
No |
Software Compatibility |
|
SuperSign CMS |
Yes |
SuperSign Control / Control+ |
Yes |
SuperSign WB |
Yes |
SuperSign Cloud |
Yes |
Mobile CMS |
Yes |
LG ConnectedCare |
Yes |
Connectivity |
|
Input |
|
HDMI In |
2, 3,840 × 2,160 @ 60 Hz, HDCP 2.2/1.4 |
DP In |
3840 × 2,160 @ 60 Hz, HDCP 2.2/1.3 |
RS-232C In |
4 Pin Phone-jack |
RJ45 (LAN) In |
Yes |
IR In |
Yes |
USB In 2.0 |
Type A, Type C (without PD function) |
Output |
|
DP Out |
3,840 × 2,160 @ 60 Hz |
Audio Out |
Yes |
RS-232C Out |
4 Pin Phone-jack |
Daisy Chain |
HDMI, DP, USB C / Output DP |
LANGUAGE |
|
OSD |
English, French, German, Spanish, Italian, Korean, Chinese (Simplified), Chinese (Original), Portuguese (Brazil), Swedish, Finnish, Norwegian, Danish, Russian, Japanese, Portuguese (Europe), Dutch, Czech, Greek, Türkçe, Arabic |
Accessory |
|
Basic |
Remote Controller, Power Cord, QSG, Regulation Book, Phone to RS-232C Gender, USB-C Cable, Cable Holder (2 ea), AC Cord Holder (1 ea) |
Optional |
Slim Wall Mount (WB21LM A/B), Normal Wall Mount (OLW480 A/B), Wall Mount Adapter (AM-B330S) |
Special Feature |
|
Tilt (Facedown) |
Yes (Max 30º degree, 40ºC temperature) |
IP Rating |
IP5X |
Conformal Coating (Power Board) |
Yes |
