Seasonic PRIME PX-1600 1600W Platinum ATX 3.0 Fully Modular PSU

Seasonic PRIME PX-1600 1600W Platinum ATX 3.0 Fully Modular PSU

Name: Seasonic PRIME PX-1600 1600W Platinum ATX 3.0 Fully Modular PSU
Brand: Seasonic
SKU: PSUSEA1600PDA3
Price: 751 AUD
Availability: InStock

SKU : PSUSEA1600PDA3

Brand : Seasonic

Availablity : Online Only, In Stock
Ships within 1 and 3 days from our Seven Hills, NSW warehouse or Pickup in 3 to 4 days

80 PLUS: Platinum, Form Factor: Intel ATX 12 V 3.0, Modularity: Fully Modular, Voltage: 100 V - 240 V, Current: 15 - 10 A, Frequency: 50 Hz - 60 Hz, 12 Years Limited Warranty, PSUSEA1600PDA3.

Ask a question about this product

$751.00

Buy Now

Estimated Shipping

Find

For Bulky items and non-metro Australia a different shipping will be quoted on order receipt.

No surcharge On Credit Card, AMEX or Paypal. American express, master card, nab, Paypal, visa

Description
Specifications
Reviews

Product Description

Manufacture # Seasonic | Model # PSUSEA1600PDA3

High-end power supplies like the Seasonic PRIME PX-1600 1600W Platinum ATX 3.0 Fully Modular PSU PSUSEA1600PDA3 are ideal for workstation and gaming systems with demanding performance requirements. Its 80 PLUS Platinum certification attests to its high efficiency and reduced power waste as heat. Additionally, because it is completely modular, you may just utilize the wires that you require, which will enhance ventilation and maintain a neat and orderly system.

Features:

80 PLUS Platinum certified
ATX 3.0 and 16-Pin PCIe Gen 5 Cable (12VHPWR)
Micro Tolerance Load Regulation (0.5 %)
Cable-free Connection Design
Premium Hybrid Fan Control - Fanless until 40 % load
Multi-GPU setup
Gold plated connectors

Overview:

80 PLUS: Platinum
Form Factor: Intel ATX 12 V 3.0
Modularity: Fully Modular
Voltage: 100 V - 240 V
Current: 15 - 10 A
Frequency: 50 Hz - 60 Hz

Manufacturer Warranty: 12 Years Limited Warranty

Technical Specifications

80 PLUS	Platinum
Cybenetics Efficiency Level	TBA
Cybenetics Noise Level	TBA
Form Factor	Intel ATX 12 V 3.0
Dimensions	210 mm (L) x 150 mm (W) x 86 mm (H)
Fan Information :-
Fan Size	135 mm
Fan Control	Premium Hybrid Fan Control
Fan Bearing	Fluid Dynamic Bearing
Life Expectancy	50,000 hours at 40 °C, 15 % - 65 % RH
Cable Information :-
Modularity	Fully Modular
Cable type	Flat black cables
Electrical Features :-
Operating Temperature	0 - 50 °C
MTBF @ 25 °C, excl. fan	150,000 hours
AC Input	Full Range
Protection	OPP, OVP, UVP, OCP, OTP, SCP
Safety and Environmental :-
Safety and EMC	cTUVus, TUV, CB, CCC, BSMI, EAC, CE
Environmental Compliance	Energy Star, RoHS, WEEE, ErP Lot 6, REACH
Power Output (AC Input) :-
Voltage	100 V - 240 V
Current	15 - 10 A
Frequency	50 Hz - 60 Hz
DC Output :-
Rail	+3.3 V, +5 V, +12 V, -12 V, +5 VSB
Maximum Power	25 A, 25 A, 108.3 A, 0.5 A, 3 A 125 W, 1300 W, 6 W, 15 W
Total Continuous Power	1600 W
