STARTECH Usb-c To Displayport Multi Monitor MSTCDP122DP

SKU : MSTCDP122DP
Brand : StarTech
Availablity : Online Only, In Stock
Ships within 1 and 3 days from our Seven Hills, NSW warehouse or Pickup in 3 to 4 days
STARTECH Usb-c To Displayport Multi Monitor MSTCDP122DP, 1 - Connector A: USB-C (24 pin) DisplayPort Alt Mode, 2 - Connector B: DisplayPort (20 pin), AV Input: USB-C, Ports: 2, AV Output: DisplayPort - 1.2, Audio: Yes, Chipset ID: MegaChips - STDP4320, VIA/VLI - VL100, Audio Specifications: DisplayPort - 5.1 Channel Audio, Maximum Cable Distance To Display: 2 m [6.6 ft], Maximum Digital Resolutions: 3840x2160 @ 30hz, Wide Screen Supported: Yes   This USB-C to DisplayPort MST Hub lets you connect two DisplayPort monitors to your USB Type-C Windows device, conveniently helping you to maximize your produc
Ask a question about this product
$93.00

Estimated Shipping

For Bulky items and non-metro Australia a different shipping will be quoted on order receipt.

No surcharge On Credit Card, AMEX or Paypal. American express, master card, nab, Paypal, visa

Share

  • Description
  • Specifications
  • Reviews

Product Description

Manufacture # Startech | Model # MSTCDP122DP



This USB-C to DisplayPort MST Hub lets you connect two DisplayPort monitors to your USB Type-C Windows device, conveniently helping you to maximize your productivity.



With devices becoming more portable than ever, you can be limited to fewer video outputs and confined to your small integrated screen. This multi-stream transport hub solves that problem by enabling you to connect two separate displays to your USB-C computer, making multitasking much easier.



Features:

  • MULTIPLE MONITORS FOR WINDOWS: USB-C to DisplayPort splitter to drive 2x 4K 30Hz or 2x 1080p 60Hz DP displays using a USB-C DP Alt-Mode port (DP 1.2/HBR2/MST) w/ no video compression; Thunderbolt 3 compatible | Not compatible with macOS
  • CONVENIENCE: With a built-in 1ft cable, this bus-powered 2-port MST hub provides an easy method to connect up to two independent screens with any DisplayPort over USB Type-C Windows host device
  • COMPATIBLE WITH: Dell XPS / Precision / Latitude, Lenovo ThinkPad X1 Carbon / Extreme, Surface Laptop 3 / Book 3 / Pro 7, HP ProBook / EliteBook / Spectre / ZBook & smaller (Mini -ITX) computers | Requires host system supporting DP Alt Mode 1.2/HBR2/MST



Overview:

  • 1 - Connector A: USB-C (24 pin) DisplayPort Alt Mode
  • 2 - Connector B: DisplayPort (20 pin)
  • AV Input: USB-C
  • Ports: 2
  • AV Output: DisplayPort - 1.2
  • Audio: Yes



Manufacturer Warranty: 03 Years Limited Warranty

Technical Specifications

Warranty 3 Years
1 - Connector A USB-C (24 pin) DisplayPort Alt Mode
2 - Connector B DisplayPort (20 pin)
Operating Temperature 5°C to 35°C (41°F to 95°F)
Storage Temperature -20°C to 60°C (-4°F to 140°F)
Humidity 50-90%
AV Input USB-C
Ports 2
AV Output DisplayPort - 1.2
Audio Yes
Chipset ID MegaChips - STDP4320, VIA/VLI - VL100
Package Height 32 mm [1.3 in]
Package Length 17.2 cm [6.8 in]
Shipping (Package) Weight 133 g [4.7 oz]
Package Width 14.3 cm [5.6 in]
Audio Specifications DisplayPort - 5.1 Channel Audio
Maximum Cable Distance To Display 2 m [6.6 ft]
Maximum Digital Resolutions 3840x2160 @ 30hz
Wide Screen Supported Yes
Color Black
Cable Length 32.4 cm [12.8 in]
Product Length 38.6 cm [15.2 in]
Product Width 58 mm [2.3 in]
Product Height 14 mm [0.6 in]
Weight of Product 44 g [1.6 oz]
Power Source USB-Powered
OS Compatibility Microsoft Windows® 10, 8/8.1, 7
Note DisplayPort 1.2 with MST+HBR2 support from the GPU is required for independent display output
Your USB-C equipped device must support video (DP alt mode) to work with this adapter
1 - Included in Package MST hub
quick-start guide
