Thermaltake Smart BX1 650W 80+ Bronze Non Modular PSU

SKU : PS-SPD-0650NNSABA-1
Brand : Thermaltake
Availablity : on order
On Order items usually have to be ordered in and may take bit longer to get them delivered from our Seven Hills, NSW warehouse
Watts: 650W, Form Factor: ATX, Power Good Signal: 100-500 msec, Hold Up Time: > 16msec at 70% of full load, MTBF: 100,000 hrs minimum, Warranty: 05 Years, PS-SPD-0650NNSABA-1.
Ask a question about this product
$96.00

Estimated Shipping

For Bulky items and non-metro Australia a different shipping will be quoted on order receipt.

No surcharge On Credit Card, AMEX or Paypal. American express, master card, nab, Paypal, visa

Share

  • Description
  • Specifications
  • Reviews

Product Description

Manufacture # Thermaltake | Model # PS-SPD-0650NNSABA-1



Built to deliver 80 PLUS Bronze with 88% power efficiency, the Smart BX1 series is available in 450W - 750W models. Constructed with a 120mm hydraulic bearing fan, Japanese main capacitors and other premium components to help deliver a continuous and stable power output at 40?, near silent operation and reliable performance.



Features:

  • Featuring a 120mm hydraulic bearing fan with intelligent RPM controls to help guarantee superior cooling performance and near silent operation.
  • All ripples are lower than 80mV on +12V, and lower than 40mV on +5V or +3.3V from 0% to 100% load to ensure a stable operation and keep your performance-critical components, such as high-end graphics cards, to function reliably for longer.
  • Providing great durability as well as offering the highest stability, while remaining reliable.
  • Powerful single +12V rail ensures a stable and reliable supply to other PC components.
  • Soft black cables come with sleeve cabling, designed to make cable installation an easy task while fully powering the system at optimal voltages
  • Smart BX1 series saves energy through its high energy efficiency up to 88% and is certified to 80 PLUS® Bronze. It has been optimized to work with all generations of Intel’s processors to achieve maximum energy saving.



Overview:

  • Watts: 650W
  • Form Factor: ATX
  • Power Good Signal: 100-500 msec
  • Hold Up Time: > 16msec at 70% of full load
  • MTBF: 100,000 hrs minimum



Manufacturer Warranty: 05 Years Limited Warranty

Technical Specifications

Watts 650W
RGB Fan No
Form Factor ATX
Model SPD-650AH2NKB-2
Type ATX 12V v2.3 and EPS v2.92
Max. Output Capacity 650W
Peak Output Capacity 780W
Color Black
Dimension ( W / H / D ) 150mm(W) x 86mm(H) x 140mm(D)
PFC (Power Factor Correction) Active PFC
Power Good Signal 100-500 msec
Hold Up Time > 16msec at 70% of full load
Input Current 10A max.
Input Frequency Range 50Hz
Input Voltage 230V~
Operating Temperature 5°C to + 40°C
Operating Humidity 20% to 85%, non-condensing
Storage Temperature -40°C to + 55°C
Storage Humidity 10% to 95%, non-condensing
Cooling System 12cm Hydraulic bearing fan
Efficiency Meet 80 PLUS Bronze 230V EU certified
MTBF 100,000 hrs minimum
Safety Approval CE, CB, TUV, EAC, RCM
PCI-E 6+2pin 2
