| Network Standard |
IEEE 802.11ax
IPv4
IPv6 |
| Product Segment |
AX11000 ultimate AX performance |
| AX technology |
Yes |
| Data Rate |
2.4GHz AX: 4x4 (Tx/Rx) 1024 QAM 20/40MHz, up to 1148Mbps
5G-1Hz AX: 4x4 (Tx/Rx) 1024 QAM 20/40/80/160MHz, up to 4804Mbps
5G-2Hz AX: 4x4 (Tx/Rx) 1024 QAM 20/40/80/160MHz, up to 4804Mbps |
| Antenna |
External antenna x 8 (non-detachable) |
| Transmit/Receive |
2.4GHz 4x4
5GHz-1 4x4
5GHz-2 4x4 |
| Processor |
2.0GHz quad-core processor |
| Memory |
256MB NAND flash and 1GB DDR4 RAM |
| Boosts speed |
OFDMA (Orthogonal Frequency Division Multiple Access)
Beamforming: standard-based and universal
1024-QAM high data rate
20/40/80/160 MHz bandwidth |
| Operating Frequency |
Tri-band Wi-Fi: 2.4 GHz / 5 GHz-1 / 5 GHz-2 |
| Ports |
1 x 2.5 Gigabit WAN Port
1 x 10 Gigabit WAN/LAN Port
4 x Gigabit LAN Ports
1 x USB 3.2 Gen 1 Port
1 x USB 2.0 Port |
| Button |
WPS Button, LED Button, Reset Button, Power Switch |
| LED Indicator |
Power x 1
2.4G x 1
5GHz-1 x 1
5GHz-2 x 1
WPS x 1
10GE x 1
LAN x 1
WAN x 1 |
| Power Supply |
AC Input : 110V~240V(50~60Hz)
DC Output : 19 V with max. 3.42 A ?19.5 V with max. 3.33 A |
| Package content |
GT-AX11000 Pro WiFi Gaming Router
RJ-45 Cable
Power Adapter
Quick Start Guide
Warranty Card |
| Product Weight (g) |
2180g |
| AiMesh |
AiMesh
Primary AiMesh router
AiMesh node |
| Router APP |
ASUS Router APP |
| Game |
Game Boost/acceleration
Game Radar
WTFast
UU boost
ROG_First
OpenNAT (Game Profile) |
| Alexa |
Support Alexa skill |
| AiProtection |
AiProtection Pro
Router Security Assessment
Malicious site blocking
Two-Way IPS
Infected Device Prevention and Blocking |
| Parental Control |
Parental Control
Parental Control Customized Internet schedule
Maximum Parental Control profile : 64
Maximum Parental Control content filter rule : 64 |
| Traffic Control |
Adaptive QoS
Bandwidth Monitor
Bandwidth limiter
Maximum Bandwidth limiter rule : 32
Traditional QoS
Traffic Monitor
Real-time traffic monitor
Wired Traffic Monitor
Wireless Traffic Monitor
Traffic Analyzer
Traffic analysis period : Daily, Weekly, Monthly
Website history |
| Wireless |
IPv6
MU-MIMO
WiFi Encryption : WPA3 Personal, WPA2 Personal, WPA Personal, WPA Enterprise, WPA2 Enterprise, Open System
UTF-8 SSID
Guest Network
Maximum Guest Network rule : 2.4 GHz x 3, 5 GHz-1 x 3, 5 GHz-2 x 3
Guest Network Connection time limit
Guest Network Encryption : Open system, WPA/WPA2-Personal/WPA3-Personal
WPS
Wi-Fi MAC address filter
Maximum MAC filters : 64
Wireless scheduler
Airtime fairness
RADIUS Client
Universal beamforming |
| WAN |
Explicit beamforming
Internet connection Type : Automatic IP, Static IP, PPPoE, PPTP, L2TP
Dual WAN
WAN Aggregation
3G/4G LTE dongle
Android tethering
Port forwarding
Maximum port forwarding rule : 64
Port triggering
Maximum port triggering rule : 32
DMZ
DDNS
NAT Passthrough : PPTP, L2TP, IPSec, RTSP, H.323, SIP Passthrough,PPPoE relay
Let's Encrypt
Safe browsing
DNS-over-TLS |
| LAN |
DHCP Server
IGMP snooping
IPTV
LAN Link Aggregation
Manually assign IP address
Maximum manually assign IP address rule : 128 |
| VPN |
VPN Client L2TP
VPN Client OVPN
VPN Client PPTP
VPN Client WireGuard
VPN Server IPSec
VPN Server OVPN
VPN Server PPTP
VPN Server WireGuard
VPN Fusion |
| USB application |
File System : HFS+, NTFS, vFAT, ext2, ext3, ext4
HDD hibernation
Safely Remove disk
AiCloud
Download master
AiDisk
Media Server
Time Machine
Samba Server
FTP Server
Shared Folder privileges |
| Administration |
Operating mode : Router(AiMesh router), AiMesh node, Access point, Repeater, Media bridge
Operating system : ASUSWRT
Free OS upgrade
Firewall
Maximum Firewall keyword filter : 64
Maximum Firewall network service filter : 32
Maximum Firewall URL filter : 64
Wake on LAN (WOL)
SSH
Configuration backup and restore
Diagnosis tools
Feedback system
System log
New Device Connect Notification
Login Captcha
Connection Diagnosis
Security Scan
Auto Firmware Update |
