Image Sensor |
1/2.7” 5Megapixel progressive scan CMOS |
Max. Resolution |
2592 (H) × 1944 (V) |
RAM/ROM |
512 MB/128 MB |
Scanning System |
Progressive |
Electronic Shutter Speed |
Auto/Manual, 1/3 s–1/100000 s |
S/N Ratio |
56 dB |
Minimum Illumination |
0.005 Lux@F1.6 |
Illumination Distance |
Distance up to 50 m (164 ft) |
Illuminator On/Off Control |
Auto/Manual |
Illuminator Number |
1 (IR LED) |
Lens Type |
Fixed-focal |
Mount Type |
Board-in |
Focal Length |
2.8 mm, 3.6 mm, 6.0 mm |
Max. Aperture |
F1.6 |
Angle of View |
H: 102°, V: 71° / H: 84°, V: 58° / H: 51°, V: 37° |
Aperture Type |
Fixed |
Close Focus Distance |
0.9 m (2.95 ft) / 1.6 m (5.25 ft) / 3.1 m (10.17 ft) |
Pan/Tilt/Rotation Range |
Pan: 0°–355°; Tilt: 0°–75°; Rotation: 0°–355° |
Event Trigger |
Motion detection, Video tampering, Scene changing, Network disconnection, IP address conflict, Illegal Access, Storage anomaly |
General Intelligence |
Object Abandoned/Missing |
Heat Map |
Yes |
Compression |
H.265, H.264, H.264B, H.264H, MJPEG (only supported by sub stream) |
Smart Codec |
Smart H.265+ / Smart H.264+ |
Streaming Capability |
3 Streams |
Resolution |
2592 × 1944 / 2688 × 1520 / 2560 × 1440 / 2304 × 1296 / 1080P / 1.3M / 720P / D1 / VGA / CIF |
Frame Rate |
Main Stream: 2592 × 1944 (1 fps–20 fps), 2560 × 1440 (1 fps–25/30 fps), 1920 × 1080 (1 fps–50/60 fps)
Sub Stream: D1 (1 fps–20/30 fps), D1 (1 fps–50 fps)
Third Stream: 1080P (1 fps–17 fps) |
Bit Rate Control |
CBR/VBR |
Bit Rate |
H.264: 32 Kbps–8192 Kbps
H.265: 19 Kbps–8192 Kbps |
Day/Night |
Auto (ICR)/Color/B/W |
BLC Mode |
BLC / HLC / WDR (120 dB) |
White Balance |
Auto / Natural / Street Lamp / Outdoor / Manual |
Gain Control |
Auto/Manual |
Noise Reduction |
3D DNR |
Motion Detection |
Off/On (4 Zone, Rectangle) |
Region of Interest |
Off/On (4 Zone) |
Smart Illumination |
Yes |
Defog |
Yes |
Flip |
0°/90°/180°/270° |
Mirror |
Off/On |
Privacy Masking |
Off/On (4 Area, Rectangle) |
Alarm Event |
No SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, motion detection, video tampering, defocus detection, scene changing, intrusion, tripwire, abandoned object, missing object, fast moving, parking detection, loitering detection, people gathering, audio detection, people counting, face detection, queue management |
Network |
RJ-45 (10/100 Base-T) |
SDK and API |
Yes |
Protocol |
IPv4, IPv6, HTTP, HTTPS, TCP, UDP, ARP, RTP, RTSP, RTCP, RTMP, SMTP, FTP, SFTP, DHCP, DNS, DDNS, QoS, UPnP, NTP, Multicast, ICMP, IGMP, NFS, PPPoE, 802.1x, SNMP |
Interoperability |
ONVIF (Profile S/G/T), CGI, Milestone, Genetec, P2P |
Storage |
NAS, FTP, SFTP, Dahua Cloud, Micro SD card (256 GB) |
Browser |
IE (newer than IE8), Chrome, Firefox, Safari (newer than Safari 12) |
Certifications |
CE-LVD: EN62368-1, CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU, FCC: 47 CFR FCC Part 15, UL/CUL: UL60950-1 CAN/CSA C22.2 No.60950-1-07 |
Power Supply |
DC 12V (±30%), PoE (802.3af) |
Power Consumption |
<6W |
Operating Conditions |
-40°C to +60°C (-40°F to +140°F) / Less than 95% RH |
Protection Grade |
IP67, IK10 |
Casing |
Metal |
