| Image Sensor |
1/1.8" Progressive Scan CMOS |
| Min. Illumination |
Color: 0.011 Lux @ (F1.4, AGC ON), 0 Lux with IR |
| Shutter Speed |
1/3 s to 1/100,000 s |
| Slow Shutter |
Yes |
| Wide Dynamic Range |
120dB |
| Day & Night |
IR Cut Filter |
| Angle Adjustment |
Pan: 0° to 355°, tilt: 0° to 90°, rotate: 0° to 360° |
| Focus |
Auto |
| Lens Type |
2.8 to 12 mm |
| FOV |
Horizontal FOV: 108.1° to 45.5° , vertical FOV: 58.4° to 25.7° , diagonal FOV: 127.3° to 52.1° |
| Aperture |
F1.4 |
| Lens Mount |
F14 |
| Aperture Type |
Fixed |
| IR Range |
Up to 60 m |
| Wavelength |
850nm |
| Max. Resolution |
3840 × 2160 |
| Main Stream |
50Hz: 20fps (3840 × 2160, 3072 × 1728), 25fps (2688 × 1520,1920 × 1080, 1280 × 720) 60Hz: 20fps (3840 × 2160, 3072 × 1728), 30fps (2688 × 1520,1920 × 1080, 1280 × 720) |
| Sub Stream |
50Hz: 25fps (640 × 480, 640 × 360, 320 × 240) 60Hz: 30fps (640 × 480, 640 × 360, 320 × 240) |
| Third Stream |
50Hz: 25fps (1280 × 720, 640 × 480, 640 × 360, 320 × 240) 60Hz: 30fps (1280 × 720, 640 × 480, 640 × 360, 320 × 240) |
| Video Compression |
Main stream: H.265/H.264,Sub-stream: H.265/H.264/MJPEG,Third stream: H.265/H.264 |
| Video Bit Rate |
32 Kbps to 16 Mbps |
| H.264 Type |
Main Profile/High Profile |
| H.265 Type |
Main Profile |
| Region Of Interest (ROI) |
1 fixed region for main stream, sub-stream and third stream |
| Environment Noise Filtering |
Yes |
| Audio Sampling Rate |
8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz |
| Audio Compression |
G.711/G.722.1/G.726/MP2L2/PCM/MP3 |
| Audio Bit Rate |
64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32-192Kbps(MP2L2)/8Kbps-320Kbps(MP3) |
| Simultaneous Live View |
Up to 6 channels |
| API |
ONVIF (PROFILE S, PROFILE G), ISAPI, SDK |
| Protocols |
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS |
| User/Host |
Up to 32 users,3 levels: Administrator, Operator and User |
| Network Storage |
microSD/SDHC/SDXC card (256 GB), local storage and NAS (NFS,SMB/CIFS), ANR |
| Client |
iVMS-4200, Hik-Connect, Hik-Central |
| Web Browser |
Plug-in required live view: IE8+, Chrome 41.0-44, Firefox30.0-51, Safari8.0-11 Plug-in free live view: Chrome 57.0+, Firefox 52.0+ |
| Alarm Trigger |
Motion detection, video tampering alarm, exception (network disconnected, IP address conflict, illegal login, HDD full, HDD error), scene change detection |
| Day/Night Switch |
Day/Night/Auto/Schedule/Triggered by Alarm In |
| Target Cropping |
No |
| DNR |
3D DNR |
| Image Enhancement |
BLC/3D DNR/HLC |
| Image Settings |
Saturation, brightness, contrast, sharpness, AGC and white balance adjustable by client software or web browser |
| Audio |
1 audio input (line in), two-core terminal block; 1 audio output(line out), two-core terminal block |
| Alarm |
1 alarm input, 1 alarm output (max. 24 VAC/24 VDC@500 mA) |
| On-Board Storage |
Built-in micro SD slot, up to 256 GB |
| Hardware Reset |
Yes |
| Communication Interface |
1 RJ45 10M/100M self-adaptive Ethernet port |
| Smart Event |
Line crossing detection, intrusion detection, region entrance detection, region exiting detection (Human&Vehicle classification) |
| Firmware Version |
V5.5.60 |
| Web Client Language |
32 languages English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil) |
| General Function |
Anti-flicker, three streams, heartbeat, mirror, privacy masks, pixel counter |
| Startup And Operating Conditions |
-30 °C to 60 °C (-22 °F to 140 °F), humidity 95% or less (non-condensing) |
| Power Supply |
12 VDC ± 25%, F 5.5 mm coaxial power plug; reverse polarity protection; PoE (802.3at, class 4) |
| Power Consumption And Current |
12 VDC, 1.12 A, max. 13.5 W; PoE (802.3at, 42.5 V to 57 V), 0.5 A to 0.3 A, max. 15 W |
| Camera Dimension |
Camera: F105 × 298 mm (F4.1" × 11.7") With package: 385 × 190 × 180 mm (15.2" × 7.5" × 7.1") |
| Camera Weight |
Camera: approx. 1360 g (3 lb.) With package: approx. 1960 g (4.3 lb.) |
| EMC |
FCC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014); RCM (AS/NZS CISPR 32: 2015); IC (ICES-003: Issue 6, 2016); KC (KN 32: 2015, KN 35: 2015) |
| Safety |
UL (UL 60950-1); CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013); CE-LVD (EN 60950-1:2005 + Am 1:2009 + Am 2:2013); BIS (IS 13252(Part 1):2010+A1:2013+A2:2015); LOA (IEC/EN 60950-1) |
| Environment |
CE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006) |
| Protection |
Ingress protection: IP67 (IEC 60529-2013), IK10(IEC 62262:2002) |
