| Image Sensor |
1/2.5" Progressive Scan CMOS |
| Min. Illumination |
Color: 0.01Lux @ (F1.2, AGC ON), 0.034Lux @ (F2.2, AGC ON), 0 Lux with IR on |
| Shutter Speed |
1/3 s to 1/100,000 s |
| Wide Dynamic Range |
120 dB |
| Day & Night |
IR cut filter with auto switch |
| Lens Type |
1.05 mm @ F2.2, horizontal field of view: 180°, vertical field of view: 180° |
| Lens Mount |
M12 |
| Max. Resolution |
2560 × 1920 |
| Main Stream |
50Hz: 25fps (2560 × 1920, 2048 × 1536, 1280 × 960),60Hz: 30fps (2560 × 1920, 2048 × 1536, 1280 × 960), |
| Sub Stream |
50Hz: 25fps (352× 288, 704 × 576),60Hz: 30fps (352 × 240, 704 × 576), |
| Video Compression |
Main stream: H.265/H.264,Sub-stream: H.265/H.264/MJPEG, |
| Video Bit Rate |
32 Kbps to 16 Mbps |
| H.264 Type |
Main Profile/High Profile |
| H.265 Type |
Main Profile |
| H.264+ |
Support |
| H.265+ |
Support |
| Region Of Interest (ROI) |
Support 1 fixed region for main stream and sub-stream |
| Audio Compression |
G.711/G.722.1/G.726/MP2L2/PCM, 8kHz/16kHz/32kHz/44.1kHZ/48kHz |
| Audio Bit Rate |
64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32-192Kbps(MP2L2) |
| API |
V5.5.52 |
| Protocols |
TCP/IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS |
| Security |
Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS 1.2, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for ONVIF, TLS1.2 |
| Day/Night Switch |
Auto/Schedule/Triggered by Alarm In (-S model supports) |
| DNR |
3D DNR |
| Distortion Correction |
Support |
| Image Enhancement |
WDR/3D DNR/Backlight Compensation/Defog |
| Image Settings |
Saturation, brightness, contrast, and sharpness are adjustable via client software or web browser |
| Display Mode |
Support table, wall, and ceiling |
| Audio |
Support |
| Alarm |
1 audio input (line in), 1 audio output interface |
| Video Output |
1 RJ45 10M/100M self-adaptive Ethernet port |
| On-Board Storage |
1 alarm input, 1 alarm output (DC24V, 1A or AC110V, 500mA, max.) |
| Communication Interface |
Built-in microSD/SDHC/SDXC slot, up to 128 G |
| Basic Event |
Motion detection, video tampering alarm, exception (network disconnected, IP address conflict, illegal login, HDD full, HDD error) |
| Smart Event |
Line crossing detection, intrusion detection, unattended baggage, object removal, face detection, scene change detection |
| Face Detection |
Motion detection, dynamic analysis, intrusion detection, line crossing detection |
| Detection |
NAS (Support NFS,SMB/CIFS), built-in microSD/SDHC/SDXC card slot, up to 128 G, ANR |
| Linkage Method |
Trigger recording: memory card, network storage, pre-record and post-record Trigger captured pictures uploading: FTP, HTTP, NAS, Email Trigger notification: HTTP, ISAPI, alarm output , Email |
| Firmware Version |
One-key reset, anti-flicker, password protection, privacy mask, IP Address filtering, heartbeat, watermark |
| Web Client Language |
32 languages English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil) |
| General Function |
Anti-flicker, three streams, heartbeat, mirror, privacy masks, password reset via e-mail, pixel counter, HTTP listening |
| Power Supply |
-10 °C to +50 °C (-14 °F to +122 °F), Humidity 95% or less (non-condensing) |
| Power Consumption And Current |
DC 12V ± 25%, 2A, 5W,PoE(802.3af 36-57V, class 3), 0.4 – 0.7 A, 6.7W, |
| Camera Weight |
Φ 119.9 × 41.2 mm (Φ 4.72″ × 1.62″) |
| Protection |
Up to 8 m |
