Image Sensor |
1/1.2" Progressive Scan CMOS |
Max. Resolution |
3840 × 2160 |
Min. Illumination |
Color: 0.0005 Lux @ (F1.0, AGC ON), 0 Lux with Light |
Shutter Time |
1/3 s to 1/100,000 s |
Angle Adjustment |
Pan: 0° to 360°, Tilt: 0° to 90°, Rotate: 0° to 360° |
Lens Type |
Fixed focal lens, 2.8 mm, 4 mm, and 6 mm optional |
Focal Length & FOV |
2.8 mm: Horizontal FOV 102°, Vertical FOV 52°, Diagonal FOV 124°
4 mm: Horizontal FOV 88°, Vertical FOV 47°, Diagonal FOV 104°
6 mm: Horizontal FOV 54°, Vertical FOV 30°, Diagonal FOV 62° |
Iris Type |
Fixed |
Aperture |
F1.0 |
Depth of Field |
2.8 mm: 4.5 m to ∞
4 mm: 7 m to ∞
6 mm: 13 m to ∞ |
DORI |
2.8 mm: D: 96 m, O: 38 m, R: 19 m, I: 10 m
4 mm: D: 102 m, O: 41 m, R: 21 m, I: 11 m
6 mm: D: 167 m, O: 66 m, R: 33 m, I: 16 m |
Supplement Light Type |
White Light |
Supplement Light Range |
40 m |
Smart Supplement Light |
Yes |
Video Compression |
Main Stream: H.265, H.264, H.264+, H.265+
Sub-stream: H.265, H.264, MJPEG
Third stream: H.265, H.264 |
Video Bit Rate |
32 Kbps to 16 Mbps |
H.264 Type |
Baseline Profile, Main Profile, High Profile |
H.265 Type |
Main Profile |
Bit Rate Control |
CBR, VBR |
Scalable Video Coding (SVC) |
H.264 and H.265 encoding |
Region of Interest (ROI) |
1 fixed region for main stream and sub-stream |
Main Stream |
50 Hz: 25 fps (3840 × 2160, 3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)
60 Hz: 24 fps (3840 × 2160), 30 fps (3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720) |
Sub-Stream |
50 Hz: 25 fps (640 × 480, 640 × 360)
60 Hz: 30 fps (640 × 480, 640 × 360) |
Third Stream |
50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360) |
Audio Compression |
G.711ulaw, G.711alaw, G.722.1, G.726, MP2L2, PCM, MP3, AAC |
Audio Bit Rate |
64 Kbps (G.711 ulaw/alaw), 16 Kbps (G.722.1/G.726), 32-192 Kbps (MP2L2), 8-320 Kbps (MP3), 16-64 Kbps (AAC) |
Audio Sampling Rate |
8 kHz, 16 kHz, 32 kHz, 44.1 kHz, 48 kHz |
Environment Noise Filtering |
Yes |
