Image Sensor |
1/2.4" Progressive Scan CMOS |
Max. Resolution |
3200 × 1800 |
Min. Illumination |
Color: 0.003 Lux @ (F1.6, AGC ON), B/W: 0 Lux with IR |
Shutter Time |
1/3 s to 1/100,000 s |
Day & Night |
IR cut filter |
Angle Adjustment |
Pan: 0° to 360°, Tilt: 0° to 90°, Rotate: 0° to 360° |
Lens Type |
Fixed focal lens, 2.8 mm, 4 mm, and 6 mm optional |
Focal Length & FOV |
2.8 mm: Horizontal FOV 105.1°, Vertical FOV 53.4°, Diagonal FOV 128.6°
4 mm: Horizontal FOV 83.9°, Vertical FOV 44.5°, Diagonal FOV 100.8°
6 mm: Horizontal FOV 47.5°, Vertical FOV 26°, Diagonal FOV 54.5° |
Lens Mount |
M12 |
Iris Type |
Fixed |
Aperture |
F1.6 |
DORI |
2.8 mm: D: 78.6 m, O: 31.2 m, R: 15.7 m, I: 7.9 m
4 mm: D: 95.6 m, O: 37.9 m, R: 19.1 m, I: 9.6 m
6 mm: D: 160.0 m, O: 63.5 m, R: 32.0 m, I: 16.0 m |
Supplement Light Type |
IR |
Supplement Light Range |
Up to 40 m |
Smart Supplement Light |
Yes |
IR Wavelength |
850 nm |
Main Stream |
50 Hz: 25 fps (3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)
60 Hz: 30 fps (3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720) |
Sub-Stream |
50 Hz: 25 fps (640 × 480, 640 × 360)
60 Hz: 30 fps (640 × 480, 640 × 360) |
Third Stream |
50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
*Third stream is supported under certain settings. |
Video Bit Rate |
32 Kbps to 16 Mbps |
Audio Type |
Mono sound |
Audio Compression |
G.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC |
Audio Bit Rate |
64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)/16 to 64 Kbps (AAC) |
Audio Sampling Rate |
8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz |
Environment Noise Filtering |
Yes |
Power |
12 VDC ± 25%, 0.54 A, max. 6.5 W, Ø5.5 mm coaxial power plug, reverse polarity protection, PoE: 802.3af, Class 3, 36 V to 57 V, 0.3 A to 0.2 A, max. 8.0 W |
Dimension |
72.9 mm × 73.3 mm × 191.1 mm (2.9" × 2.9" × 7.5") |
Material |
Metal |
Weight |
Approx. 580 g (1.3 lb.) |
Storage Conditions |
-30 °C to 60 °C (-22 °F to 140 °F), Humidity 95% or less (non-condensing) |
Protection |
IP67: IEC 60529-2013 |
