Display System |
3LCD system |
Size of Effective Display Area |
0.64” (16.3 mm) x 3 BrightEra LCD Panel, Aspect ratio: 16:10 |
Number of Pixels |
6,912,000 (1920 x 1200 x 3) pixels |
Focus |
Manual |
Zoom |
Manual (Approx. x 1.6) |
Lens shift |
Manual, Vertical –35% to +55%, Horizontal: +/–15% |
Throw Ratio |
1.23: 1 to 1.97: 1 |
Light Source |
Laser diode |
Screen Size |
1.02 m to 7.62 m (40 in to 300 in) (measured diagonally) |
Mode: Standard |
6,400 lm*2 / 7,000 lm (Center)*3 |
Mode: Middle |
4,700 lm |
Mode: Standard |
6,400lm |
Mode: Middle |
4,700 lm |
Contrast Ratio (full white / full black)*1 |
∞:1 |
Horizontal |
15 kHz to 92 kHz |
Vertical |
24 Hz to 92 Hz |
Keystone Correction (Max.) |
Horizontal: +/-30 degrees
Vertical: +/-30 degrees |
Computer Signal Input |
Maximum signal resolution: 1920 x 1200*4 |
Video Signal Input |
NTSC, PAL, SECAM, 480/60i, 576/50i, 480/60p, 576/50p, 720/60p, 720/50p, 1080/60i, 1080/50i, 1080/60p, 1080/50p, 3840/60p, 3840/30p, 3840/25p, 3840/24p, 4096/60p, 4096/30p, 4096/25p, 4096/24p |
INPUT A |
RGB / Y PB PR input connector: Mini D-sub 15 pin (female)
Audio input connector: Stereo mini jack |
INPUT B |
HDMI input connector: HDMI 19-pin, Digital RGB/Y PB PR, HDCP support
Audio input connector: HDMI audio support |
INPUT C |
HDMI input connector: HDMI 19-pin, Digital RGB/Y PB PR, HDCP support
Audio input connector: HDMI audio support |
INPUT D |
HDBaseT interface connector: RJ45, 4 play (Video, Audio, LAN, Control) |
VIDEO IN |
Video input connector: Phono jack (Composite)
Audio input connector: Shared with INPUT A |
OUTPUT |
Audio output connector: Stereo mini jack |
REMOTE |
D-sub 9-pin (male) / RS232C |
LAN |
RJ45, 10BASE-T / 100BASE-TX |
USB |
TYPE-A x 1 (for F/W update), TYPEA for Power supply |
Speaker |
16 W |
OSD Languages |
27-language (English, French, German, Italian, Spanish, Portuguese, Japanese, Chinese, Korean, Russian, Dutch, Norwegian, Swedish, Thai, Arabic ,Turkish, Polish, Vietnamese, Farsi, Finnish, Indonesian, Hungarian, Greek, Czech, Slovak, Romanian) |
Acoustic noise (Mode: Standard / Middle) *1 |
37 dB / 34 dB |
Operating Temperature / Operating Humidity |
0°C to 40°C (32°F to 104°F) / 20% to 80% (no condensation) |
Storage Temperature / Storage Humidity |
-10°C to +60°C (14°F to +140°F) / 20% to 80% (no condensation) |
Power Requirements |
AC 100 V to 240 V, 4.7 A to 2.0 A, 50 Hz/60 Hz |
AC 100 V to 120 V |
463 W |
AC 220 V to 240 V |
434 W |
AC 100 V to 120 V |
0.5 W (when “Standby mode” is set to “Low”) |
AC 220 V to 240 V |
0.5 W (when “Standby mode” is set to “Low”) |
AC 100 V to 120 V |
1 W (LAN), 21 W (ALL Terminals and Networks Connected / exclude USB Device and speaker off, when “Standby Mode” is set to “Standard”) |
AC 220 V to 240 V |
1 W (LAN), 21 W (ALL Terminals and Networks Connected / exclude USB Device and speaker off, when “Standby Mode” is set to “Standard”) |
Standby Mode / Networked Standby Mode Activated |
Approx. 2 Minutes |
Dimensions (W x H x D) (without dust filter, protrusions) |
Approx. 422 x 100 x 333 mm (16 5/8 x 3 15/16 x 13 1/8 inches) |
Mass |
Approx. 7.0 kg (15 lb) |
Supplied Accessories |
RM-PJ8 Remote Commander |
