Display system |
3 LCD system |
Size of effective display area |
1” x 3 BrightEra LCD Panel, Aspect ratio: 16:10 |
Number of pixels |
6,912,000 (1920 x 1200 x 3) pixels |
Aspect ratio |
0.673611111111111 |
Resolution |
WUXGA (1920 x 1200 pixels) |
Focus |
Powered/Manual(Depend on lens) |
Zoom - Powered/Manual |
Powered/Manual(Depend on lens) |
Zoom - Ratio |
Depend on Lens |
Throw ratio |
Depend on Lens |
Lens shift - Powered/Manual |
Powered |
Lens shift - Range Vertical/Horizontal |
Range Vertical: Depend on Lens
Range Horizontal: Depend on Lens |
Type |
Laser diode |
Filter replacement cycle (Max.) |
10,000 H (service maintenance) |
Screen size |
Depend on Lens |
Mode: Standard |
9,000lm *2 / 9,800lm (Center)*3 |
Mode: Middle |
8,000lm |
Mode: Low |
7,000lm |
Mode: Standard |
9,000lm |
Mode: Middle |
8,000lm |
Mode: Low |
7,000lm |
Contrast ratio: |
∞ : 1 |
Horizontal |
15 kHz to 92 kHz |
Vertical |
48 Hz to 92 Hz |
Computer signal input |
Maximum signal resolution: 1920 x 1200 |
Video signal input |
480/60i, 576/50i, 480/60p, 576/50p, 720/60p, 720/50p, 1080/60i, 1080/50i
The following items are available for digital signal only; 1080/60P, 1080/50p, 1080/24p, 1080/30p *4 |
Horizontal |
+/- 30 degrees |
Vertical |
+/- 30 degrees |
INPUT A |
RGB / Y PB PR input connector: 5 BNC (female) |
INPUT B |
RGB input connector: Mini D-sub 15-pin (female) |
INPUT C |
DVI input connector: DVI-D 24-pin (single link), HDCP support
HDCP: v1.4 |
INPUT D |
HDMI input connector: HDMI 19-pin, HDCP support
HDCP: v1.4 |
INPUT E |
HDBaseT interface connector: RJ45, 3 play |
INPUT F |
Optional adaptor slot for 3G-SDI Input Adaptor (BKM-PJ20) |
INPUT G |
HTML Viewer |
OUTPUT 1 |
Monitor output for Input A/Input B Connector: Mini D-sub 15-pin (female) |
USB-1 |
Type-A x 1 |
USB-2 |
Type-B x 1 (for service) |
REMOTE |
D-sub9pin male/RS232C |
LAN |
RJ45, 10BASE-T/100BASE-TX/1000BASE-T |
Light output mode: Standard |
39dB |
Light output mode: Middle |
39dB |
Operating temperature / Operating humidity |
0°C to 45°C (32°F to 109°F) / 20% to 80% (no condensation) |
Storage temperature / Storage humidity |
-10°C to +60°C (14°F to +140°F) / 20% to 80% (no condensation) |
Power requirements |
AC 100 V to 240 V, 8.4 A to 3.4 A, 50 Hz / 60 Hz |
AC 100 V to 120 V |
840 W |
AC 220 V to 240 V |
814 W |
AC 100 V to 120 V |
0.50W (when “Standby mode” is set to “Low”) |
AC 220 V to 240 V |
0.50W (when “Standby mode” is set to “Low”) |
AC 100 V to 120 V |
21.6W (LAN)
26.5W (HDBT)
26.6W (ALL Terminals and Networks Connected, when "Standby Mode" is set to "Standard") |
AC 220 V to 240 V |
21.3W (LAN)
26.5W (HDBT)
26.6W (ALL Terminals and Networks Connected, when "Standby Mode" is set to "Standard") |
Standby Mode / Networked Standby Mode Activated |
Approx. 2 Minutes |
AC 100 V to 120 V |
2866 BTU/h |
AC 220 V to 240 V |
2777 BTU/h |
Dimensions (W x H x D) (without protrusions) |
Approx. 544 x 205 x 564 mm
(21 13/32 x 8 1/16 x 22 7/32 inches) |
Mass |
Approx. 26 kg (58 lb) |
Remote commander |
RM-PJ30 |
Projection Lens |
VPLL-Z4107, 4008, Z4111, Z4015, Z4019, Z4025, Z4045 |
