Hard Specification:- |
|
CPU Model |
Intel Xeon D-1531 |
CPU Quantity |
1 |
CPU Architecture |
64-bit |
CPU Frequency |
6-core 2.2 (base) / 2.7 (turbo) GHz |
Hardware Encryption Engine (AES-NI) |
Yes |
System Memory |
16 GB DDR4 ECC SODIMM |
Memory Module Pre-installed |
16 GB (8 GB x 2) |
Total Memory Slots |
4 |
Maximum Memory Capacity |
48 GB (8 GB x 2 + 16 GB x 2) |
Drive Bays |
12 |
Maximum Drive Bays with Expansion Unit |
36 (DX1222 x 2) |
Compatible Drive Type* (See all supported drives) |
3.5" SATA HDD
2.5" SATA HDD
2.5" SATA SSD |
Hot Swappable Drive* |
Yes |
RJ-45 1GbE LAN Port* |
2 (with Link Aggregation / Failover support) |
RJ-45 10GbE LAN Port |
2 (with Link Aggregation / Failover support) |
Out-of-Band Management LAN Port |
1 |
USB 3.2 Gen 1 Port* |
2 |
Expansion Port |
2 |
PCIe Expansion |
1 x Gen3 x8 slot (x8 link) |
Internal Drives |
Btrfs
EXT4 |
External Drives |
Btrfs
EXT4
EXT3
FAT
NTFS
HFS+
exFAT |
Size (Height x Width x Depth) |
270 mm x 300 mm x 340 mm |
Weight |
9.8 kg |
System Fan |
120 mm x 120 mm x 2 pcs |
Fan Speed Mode |
Full-Speed Mode
Cool Mode
Quiet Mode |
Easy Replacement System Fan |
Yes |
Power Recovery |
Yes |
Noise Level* |
25 dB(A) |
Scheduled Power On / Off |
Yes |
Wake on LAN / WAN |
Yes |
Power Supply Unit / Adapter |
550 W |
AC Input Power Voltage |
100V to 240V AC |
Power Frequency |
50/60 Hz, Single Phase |
Power Consumption |
94.42 W (Access)
54.33 W (HDD Hibernation) |
British Thermal Unit |
322.39 BTU/hr (Access)
185.51 BTU/hr (HDD Hibernation) |
Operating Temperature |
0°C to 40°C (32°F to 104°F) |
Storage Temperature |
-20°C to 60°C (-5°F to 140°F) |
Relative Humidity |
5% to 95% RH |
Certification |
FCC
CE
BSMI
VCCI
RCM
UKCA
EAC
KC
UL |
Environment |
RoHS Compliant |
Software Specifications:- |
|
Maximum Single Volume Size |
200 TB (32 GB memory required)
108 TB |
Maximum Internal Volume Number |
256 |
SSD Read / Write Cache (White Paper) |
Yes |
SSD TRIM |
Yes |
RAID Group |
Yes |
Supported RAID Type |
RAID F1
Basic
JBOD
RAID 0
RAID 1
RAID 5
RAID 6RAID 10 |
RAID Migration |
Basic to RAID 1
Basic to RAID 5
RAID 1 to RAID 5
RAID 5 to RAID 6 |
Volume Expansion with Larger HDDs |
RAID F1
RAID 1
RAID 5
RAID 6
RAID 10 |
Volume Expansion by Adding a HDD |
RAID F1
JBOD
RAID 5
RAID 6 |
Global Hot Spare Supported RAID Type |
RAID F1
RAID 1
RAID 5
RAID 6
RAID 10 |
File Protocol |
SMB/AFP/NFS/FTP/WebDAV |
Maximum Concurrent SMB/AFP/FTP Connections |
4000 |
Maximum Concurrent SMB/AFP/FTP Connections (with RAM expansion) |
10000 |
Windows Access Control List (ACL) Integration |
Yes |
NFS Kerberos Authentication |
Yes |
Maximum Local User Accounts |
16000 |
Maximum Local Groups |
512 |
Maximum Shared Folder |
512 |
Maximum Shared Folder Sync Tasks |
32 |
Hybrid Share Folder Number |
15 |
Synology High Availability |
Yes |
Syslog Events per Second |
3000 |
VMware vSphere with VAAI |
Yes |
Citrix Ready |
Yes |
OpenStack |
Yes |
Networking Protocols |
SMB1 (CIFS), SMB2, SMB3, NFSv3, NFSv4, NFSv4.1, NFS Kerberized sessions, iSCSI, Fibre Channel, HTTP, HTTPs, FTP, SNMP, LDAP, CalDAV |
Supported Browsers |
Google Chrome
Firefox
Microsoft Edge
Safari |
Maximum Users |
4000 |
Maximum Number of Concurrent Users |
500 |
Maximum Concurrent Download Tasks |
80 |
Maximum iSCSI Target Number |
256 |
Maximum LUN |
512 |
LUN Clone/Snapshot, Windows ODX |
Yes |
Maximum Number of Concurrent Users |
800 |
Maximum Server Performance |
4,235,000 emails per day, approx. 129 GB |
DLNA Compliance |
Yes |
Facial Recognition |
Yes |
Maximum Snapshots per Shared Folder |
1024 |
Maximum of System Snapshots |
65536 |
Maximum Users |
2900 |
Maximum Connections |
60 |
