Hardware Specifications:- |
|
CPU Model |
AMD Ryzen R1600 |
CPU Quantity |
1 |
CPU Architecture |
64-bit |
CPU Frequency |
2-core 2.6 (base) / 3.1 (turbo) GHz |
Hardware Encryption Engine (AES-NI) |
Yes |
System Memory |
2 GB DDR4 ECC |
Drive Bays |
4 |
Hot Swappable Drive* |
Yes |
RJ-45 1GbE LAN Port* |
2 (with Link Aggregation / Failover support) |
USB 3.2 Gen 1 Port* |
1 |
PCIe Expansion |
1 x Gen3 x2 network upgrade slot |
Internal Drives |
Btrfs
EXT4 |
External Drives |
Btrfs
EXT4
EXT3
FAT
NTFS
HFS+
exFAT |
Form Factor (RU) |
1U |
Size (Height x Width x Depth) |
44 mm x 478 mm x 327.5 mm |
Weight |
4.38 kg |
Rack Installation Support* |
4-post 19" rack (Synology Rail Kit - RKM114/RKS-02)
2-post 19" rack (direct mounting) |
System Fan |
40 mm x 40 mm x 3 pcs |
Fan Speed Mode |
Full-Speed Mode
Cool Mode
Quiet Mode |
Power Recovery |
Yes |
Noise Level* |
28.5 dB(A) |
Scheduled Power On / Off |
Yes |
Wake on LAN / WAN |
Yes |
Power Supply Unit / Adapter |
100 W |
AC Input Power Voltage |
100V to 240V AC |
Power Frequency |
50/60 Hz, Single Phase |
Power Consumption |
37.93 W (Access)
13.43 W (HDD Hibernation) |
British Thermal Unit |
129.42 BTU/hr (Access)
45.83 BTU/hr (HDD Hibernation) |
Operating Temperature |
0°C to 35°C (32°F to 95°F) |
Storage Temperature |
-20°C to 60°C (-5°F to 140°F) |
Relative Humidity |
5% to 95% RH |
Certification |
FCC
CE
BSMI
VCCI
RCM
UKCA
EAC
CCC
KC |
Environment |
RoHS Compliant |
Software Specifications :- |
|
Maximum Single Volume Size* |
108 TB |
Maximum Internal Volume Number |
64 |
SSD Read / Write Cache (White Paper) |
Yes |
SSD TRIM |
Yes |
Supported RAID Type |
Synology Hybrid RAID
Basic
JBOD
RAID 0
RAID 1
RAID 5
RAID 6
RAID 10 |
RAID Migration |
Basic to RAID 1
Basic to RAID 5
RAID 1 to RAID 5
RAID 5 to RAID 6 |
Volume Expansion with Larger HDDs |
Synology Hybrid RAID
RAID 1
RAID 5
RAID 6
RAID 10 |
Volume Expansion by Adding a HDD |
Synology Hybrid RAID
JBOD
RAID 5 |
Global Hot Spare Supported RAID Type |
Synology Hybrid RAID
RAID 1
RAID 5 |
File Protocol |
SMB/AFP/NFS/FTP/WebDAV |
Maximum Concurrent SMB/AFP/FTP Connections |
500 |
Windows Access Control List (ACL) Integration |
Yes |
NFS Kerberos Authentication |
Yes |
Maximum Local User Accounts |
2048 |
Maximum Local Groups |
256 |
Maximum Shared Folder |
512 |
Maximum Shared Folder Sync Tasks |
8 |
Maximum Hybrid Share Folders |
10 |
Synology High Availability |
Yes |
Syslog Events per Second |
800 |
Networking Protocols |
SMB1 (CIFS), SMB2, SMB3, NFSv3, NFSv4, NFSv4.1, NFS Kerberized sessions, iSCSI, HTTP, HTTPs, FTP, SNMP, LDAP, CalDAV |
Supported Browsers |
Google Chrome
Firefox
Microsoft Edge
Safari |
Maximum Concurrent Download Tasks |
80 |
Maximum iSCSI Target Number |
128 |
Maximum LUN |
256 |
LUN Clone/Snapshot, Windows ODX |
Yes |
DLNA Compliance |
Yes |
Facial Recognition |
Yes |
Maximum Snapshots per Shared Folder |
1024 |
Maximum of System Snapshots |
65536 |
Maximum Users |
200 |
Maximum Connections |
40 |
