Dual Camera |
PTZ optical zoom lens
Image sensor: Sony 4K EXMOR, crystal clear in any lighting
Frame rates: (16:9) 4K 30fps; 1920 x 1080, 1600 x 900, 1280 x 720, 960 x 540, 848 x 480, 800 x 448, 640 x 360, at 60, 30, 15fps; (4:3) 1280 x 960, 800 x 600, 640 x 480 at 60, 30, 15fps
24X Zoom*: 12X optical; 2X digital zoom
Wide field of view: DFOV 85°; HFOV 76°; VFOV 46°
Lens focal length: 3.9mm (wide) ~ 47.3mm (tele)
Lens F#: 1.8 (wide) ~ 2.8 (tele)
AE, white balance: auto, manual override via PTZApp 2
Minimum focus distance: 1.5m
Motorized Pan & tilt: Pan: ±170°;Tilt: +90° (up) -30° (down)
Preset number: 10 via IR remote, 128 via RS232
Secondary fixed lens (AI lens)
Image sensor: Sony 4K EXMOR
Frame rates and resolution set according to PTZ lens settings
Wide field of view: DFOV 95°; HFOV 78°; VFOV 50° |
HDMI & PoE |
HDMI 1.3: 1080p 30fps/ 60fps
PoE+: 802.3at |
USB |
3.1 Gen 1, backward compatible with USB 2.0
UVC 1.1 (USB video), UVC1.5* |
Power Supply |
AC 100V–240V, 50/60 Hz; Consumption: 12V, 2A
PoE+: 802.3 at |
Innovative features |
Dynamic auto framing: secondary AI lens detects all participants, new participants trigger PTZ lens to dynamically frame all participants.
Preset framing tracks both preset area and speaker*
Simultaneous 3-way output: USB, HDMI and IP connections
Gesture control provides intuitive camera controls
HDMI Picture in Picture (PIP) function
Smart gallery** function offers great visibility for individual participant in the meeting room
Cableless access to meetings: Get rid of USB cable connections with AVer virtual USB streaming technology*** (One RJ45 cable transfers IP streaming to USB.)
Audio tracking support: Integration with 3rd party ceiling microphone (Shure/Sennheiser) via AVer Preset Link*** function. |
Connectivity |
USB type-B 3.1 connector, backward compatible with USB 2.0
12V/2A DC jack power adapter
Mini DIN9 for RS232 in & out connection (VISCA control panel and camera daisy-chain)
IP (RJ45)
HDMI |
Video Format |
YUV, YUY2, MJPEG
Network video compression format: H.264, H.265
Network protocol: RTSP, RTMP |
Control |
IR remote control
VISCA/pelco P/pelco D via RS232 (128 preset points via VISCA command)
Remote side: VISCA over IP, IP (RJ45)
UVC plug and play
WebUI: Browser IP access via Chrome. (Not support IE)
OSD setting: HDMI out to TV monitor
PTZApp 2 |
Optional Accessories |
Mini DIN8 to D-Sub9 cable
Ceiling mount*
Foldable TV mount
USB2.0 type-B to type-A cable (5 m)
USB 3.1 Extension Cable (10 m/20 m/30 m)
1-Port POE+ Injector
*For ceiling mounting, please purchase the AVer ceiling mount. |
Security and Mount |
Kensington lock
1/4' tripod mounting screw
Camera wall-mount bracket included
Optional foldable TV mount
Optional ceiling mount |
Package Contents |
CAM550 unit
Power adapter (10 ft/3 m)
USB 3.1 type-B to type-A cable (3m)
Remote control
Mini DIN9 to mini DIN8 RS232 adapter cable
HDMI cable (3 m)
Wall mount bracket and screws
QR code card
Tripod screw
Drill paper |
System Requirements |
Windows 7/10/11
Mac OS X 10.14 or later
Chromebox 3 version 94.0.4606.114 or later |
Hardware Specs |
3.2 GHz Intel Core i5-4460 processor
4 GB RAM or more
USB 3.1 port, backward compatible with USB 2.0 |
Compatible Applications |
Zoom, Microsoft Teams, Skype, Skype for Business, Google Meet, RingCentral, BlueJeans , Intel Unite, Fuze, Adobe Connect, CyberLink U Meeting, Cisco WebEx GoToMeeting, LiveOn, Microsoft Lync, TrueConf, V-Cube, Vidyo, vMix, WebRTC, Wirecast, XSplit |
Environment Data |
Operation temperature: 0 to 40°C
Operation humidity: 20% to 80%
Storage temperature: -20 to 60°C
Storage humidity: 20% to 80% |
Dimensions |
Camera: 170.8 (L) X 190.5 (H) X 173 (D) mm/ 2.1kg
Remote control: 200 x 50 x 21 mm/90g |
