QNAP TDS-H2489FU 24-Bay Diskless NAS 2x Xeon Silver 4314 128GB Enclosure TDS-h2489FU-4314-128G

SKU : TDS-h2489FU-4314-128G
Brand : QNAP
Availablity : on order
On Order items usually have to be ordered in and may take bit longer to get them delivered from our Seven Hills, NSW warehouse
CPU Architecture: 64-bit x86, System Memory: 128 GB RDIMM, Drive Bay: 24 x 2.5-inch, Form Factor: Rackmount, Buttons: Power, Reset, OLED, System Warning: Buzzer, 03 Years Limited Warranty, TDS-h2489FU-4314-128G.
Ask a question about this product
$24,394.00

Estimated Shipping

For Bulky items and non-metro Australia a different shipping will be quoted on order receipt.

No surcharge On Credit Card, AMEX or Paypal. American express, master card, nab, Paypal, visa

Share

  • Description
  • Specifications
  • Reviews

Product Description

Manufacture # QNAP | Model # TDS-h2489FU-4314-128G



Featuring dual Intel Xeon Silver 4300 processors and 24 U.2 NVMe Gen 4 x4 SSD bays, the QNAP’s flagship NVMe all-flash storage TDS-h2489FU delivers high random read/write IOPS for tackling I/O-intensive and latency-sensitive applications. The ZFS-based QuTS hero operating system supports inline data deduplication and compression for reducing I/O and SSD storage consumption, which significantly extends SSD lifespan with a higher price-performance ratio for all-flash storage arrays.



Features:

  • Inline data deduplication and compression, Pool Over-provisioning, and TRIM maximize SSD performance and lifespan.
  • Dual 25GbE SFP28 and quad 2.5GbE RJ45 high-speed connectivity accelerates virtualization, intensive file access, and large backup/restoration tasks.
  • Allows for installing 10/25/40/100GbE adapters, QM2 cards, or Fibre Channel cards to increase application performance.
  • Supports virtualization storage and hosting virtual machines and containerized apps.
  • Realizes hybrid cloud applications by working with the cache space reserved on NAS to ensure low-latency data access to the cloud.
  • Scalable design to grow with your business by connecting SAS 12Gb/s expansion enclosures for up to petabyte-scale storage capacity.


Overview:

  • CPU Architecture: 64-bit x86
  • System Memory: 128 GB RDIMM
  • Drive Bay: 24 x 2.5-inch
  • Form Factor: Rackmount
  • Buttons: Power, Reset, OLED
  • System Warning: Buzzer



Manufacturer Warranty: 03 Years Limited Warranty

Technical Specifications

CPU 2 x Intel Xeon Silver 4314 16-core/32-thread processor, up to 3.4 GHz
CPU Architecture 64-bit x86
Floating Point Unit Yes
Encryption Engine Yes (AES-NI)
System Memory 128 GB RDIMM DDR4 ECC (8 x 16 GB)
Maximum Memory 1 TB (32 x 32 GB)
Memory Slot 32 x RDIMM DDR4 ECC (16 x slots per socket)
Flash Memory 5GB (Dual boot OS protection)
Drive Bay 24 x 2.5-inch
Drive Compatibility 2.5-inch bays: 2.5-inch SATA solid state drives (#17-24)
2.5-inch U.2 NVMe PCIe Gen4 x4 solid state drives
Hot-swappable Yes
M.2 Slot 2
Slot 1: M.2 2280 NVMe PCIe Gen 3 x4 or SATA 6Gb/s
Slot 2: M.2 2280 NVMe PCIe Gen 3 x2 or SATA 6Gb/s
SSD Cache Acceleration Support Yes
SR-IOV Yes
2.5 Gigabit Ethernet Port (2.5G/1G/100M) 4 (2.5G/1G/100M/10M)
25 Gigabit Ethernet Port 2 x 25GbE SFP28 SmartNIC port
Wake on LAN (WOL) Yes
Jumbo Frame Yes
PCIe Slot 2
Slot 1: PCIe Gen4 x16
Slot 2: PCIe Gen4 x8
USB 3.2 Gen 1 port 4
Form Factor Rackmount
LED Indicators SSD, Status, Power, Fan, Temperaure, Power Module Status, Device Name, IP Address
Buttons Power, Reset, OLED
Dimensions (HxWxD) 88.3 × 446.2 × 713.2 mm
Weight (Net) 21.31 kg
Weight (Gross) 27.6 kg
Operating Temperature 0 - 35°C (32°F - 95°F)
Storage Temperature -20 - 70°C (-4°F - 158°F)
Relative Humidity 5-95% RH non-condensing, wet bulb: 27?C (80.6?F)
Power Supply Unit 1200W PSU(x2), 100-240Vac
Max Wattage: 1200W@200-240Vac
1000W@100-127Vac
Power Consumption: Operating Mode, Typical 467.59 W
Fan 6 x 60mm, 12VDC
System Warning Buzzer
Max. Number of Concurrent Connections (CIFS) - with Max. Memory 10,000
