Ubiquiti Networks WiFiMan Wizard Portable Spectrum Analyzer

Name: Ubiquiti Networks WiFiMan Wizard Portable Spectrum Analyzer
Brand: Ubiquiti
SKU: WM-W
Price: 224 AUD
Availability: InStock

SKU : WM-W

Brand : Ubiquiti

Availablity : on order
On Order items usually have to be ordered in and may take bit longer to get them delivered from our Seven Hills, NSW warehouse

Enclosure material: Plastic, Weatherproofing: IP55, Management interface: Bluetooth, Power supply: Rechargeable Li-ion battery, 3.7V DC, 300mAh, Max. power consumption: 32.4mW, Charger voltage: USB-C, 5V DC/1A, Warranty: 01 Year, WM-W.

Ask a question about this product

$224.00

Buy Now

Estimated Shipping

Find

For Bulky items and non-metro Australia a different shipping will be quoted on order receipt.

No surcharge On Credit Card, AMEX or Paypal. American express, master card, nab, Paypal, visa

Description
Specifications
Reviews

Product Description

Manufacture # Ubiquiti | Model # WM-W

The Ubiquiti WiFiMan Spectrum Analyser is a portable wizard device created for WifiMan iOS and Android apps and features 2.4GHz and 5 GHz unlicensed band scanning, 240 minutes continuous scanning battery life, BLE smartphone pairing with USB-C charging port, and iPhone Magsafe attachable support.

Features:

2.4 GHz and 5 GHz unlicensed band scanning
240 minutes continuous scanning battery life
BLE smartphone pairing with USB-C charging port
iPhone Magsafe attachable support (A mag-safe case is required to attach this device to an iPhone.)

Overview:

Enclosure material: Plastic
Weatherproofing: IP55
Management interface: Bluetooth
Power supply: Rechargeable Li-ion battery, 3.7V DC, 300mAh
Max. power consumption: 32.4mW
Charger voltage: USB-C, 5V DC/1A

Manufacturer Warranty: 01 Year Limited Warranty

Technical Specifications

Mechanical :-
Dimensions	78.5 x 50.5 x 7.9 mm (3.1 x 2 x 0.3")
Weight	32 g (1.1 oz)
Enclosure material	Plastic
Weatherproofing	IP55
Hardware :-
Management interface	Bluetooth
Power method	Li-ion battery
Power supply	Rechargeable Li-ion battery, 3.7V DC, 300mAh
Max. power consumption	32.4mW
Charger voltage	USB-C, 5V DC/1A
LED	White/blue/red
Buttons	(1) Power (1) Factory-reset
Operating temperature	0 to 40° C (32 to 104° F)
Operating humidity	10 to 90% noncondensing
Certifications	CE, FCC, IC
SSID Scan :-
Frequency range	2.4 to 2.5 GHz 5.15 to 5.85 GHz
Amplitude range	-96 dBm to 0 dBm
Amplitude resolution	1 dBm
Software :-
Management application	UniFi WiFiman iOS: Version 0.18.0 and later UniFi WiFiman Android: Version 1.15.0 and later
