CAMERA :- |
|
Image Sensor |
1/2.7" Progressive Scan CMOS |
Shutter Speed |
1/3 to 1/10000 s |
Slow Shutter |
Yes |
Minimum Illumination |
0.005 Lux; 0 Lux with IR/white light |
Day/Night Mechanism |
IR Cut Filter |
Day/Night Switch |
Day/Night/Auto/Schedule-Switch |
LENS :- |
|
Type |
Fixed Focal Lens |
Focal Length |
4 mm |
Aperture |
4 mm: F1.6 |
FOV |
4mm: Horizontal FOV: 90°, Vertical FOV: 48°, Diagonal FOV: 107° |
Lens Mount |
M12*P 0.5 |
DORI Distance |
4 mm
Detect: 80 m (262 ft)
Observe: 33 m (109 ft)
Recognize: 16 m (52 ft)
Identify: 8 m (26 ft) |
VIDEO :- |
|
Max. Resolution |
2880 x 1620 |
Main Stream |
Frame Rate:
50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps
60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps
Resolution:
2880x1620,2688x1520, 2304x1296, 2048x1280, 1920x1080,1280x720
Note: If the image rotation is set to 90° or 270°, the frame rate only supports up to 20fps. |
Sub-Stream |
Frame Rate:
50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps
60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps
Resolution:
704x576,640x480, 352x288, 320x240
Note: If the image rotation is set to 90° or 270°, the frame rate only supports up to 20fps. |
Bit Rate Control |
CBR, VBR |
Video Compression |
Main Stream: H.265+/H.265/H.264+/H.264
Sub-Stream: H.265/H.264 |
H.264 Type |
Main Profile/High Profile |
H.264+ |
Main Stream Supported |
H.265 Type |
Main Profile |
H.265+ |
Main Stream Supported |
Video Bit Rate |
Main Stream: 256 Kbps to 6 Mbps
Sub-Stream: 64 Kbps to 512 Kbps |
ILLUMINATOR :- |
|
IR LED |
Quantity: 1
Range: 30m
Wavelength: 850nm |
White LED |
Quantity: 1
Range: 30m |
Illuminator On/Off Control |
Auto/Scheduled/Always on/Always off |
ANGLE ADJUSTMENT (MANUAL) :- |
|
Range |
Pan: 0° to 360°, Tilt: 0° to 85° |
IMAGE :- |
|
Image Settings |
Mirror, Brightness, Contrast, Saturation, Sharpness, Exposure, WDR, White Balance, Prevent Overexposure to Infrared Light, HLC Adjustable by Client Software |
Image Enhancement |
BLC/3D DNR/HLC/SmartIR |
Wide Dynamic Range |
120 dB |
SNR |
≥ 52 dB |
Image Parameters Switch |
Yes |
Privacy Mask |
Up to 4 Masks |
ROI |
1 Region |
OSD Setting |
Yes |
AUDIO :- |
|
Audio Communication |
N/A |
Audio Input |
Yes |
Audio Output |
N/A |
Audio Compression |
Yes |
Audio Sampling Rate |
8KHz |
Environment Noise Filtering |
Yes |
Audio Bit Rate |
64 Kbps(G.711 alaw) |
NETWORK :- |
|
Security |
Password Protection, HTTPS Encryption, IP Address Filter, Digest Authentication |
Protocol |
TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS |
Network Storage |
NAS (NFS, SMB/ CIFS) |
API |
Open Network Video Interface (Profile S) |
Simultaneous Live View |
3 Main Streams & 3 Sub-Streams |
Client |
VIGI App, VIGI Security Manager, VIGI NVR, Web |
Web Browser |
Google Chrome 57 and above
Firefox® 52 and above
Safari® 11 and above
Microsoft® Edge 91 and above |
Cloud |
Yes |
ONVIF |
Yes |
INTERFACES :- |
|
Network Interface |
1 RJ45 10/100M Self-Adaptive Ethernet Port, PoE |
Alarm |
N/A |
Reset Button |
Yes |
Power |
DC Power Port |
On-board Storage |
Built-In Memory Card Slot, Support MicroSD Card, up to 256 GB |
Built-in Microphone |
Yes; Records Anything Going on within a 15-ft Radius of the Camera |
Built-in Speaker |
N/A |
Audio |
N/A |
ALARM AND EVENT MANAGEMENT :- |
|
Smart Event |
Human & Vehicle Classification, Area Intrusion Detection, Line-Crossing Detection, People Detection, Vehicle Detection, Region Entering Detection, Region Exiting Detection, Object Abandoned Detection, Object Removal Detection, Loitering Detection |
Basic Event |
Motion Detection, Video Tampering Detection, Exception ( Illegal Login), Scene Change Detection |
Alarm Linkage |
Memory Card Video Recording, Message Push, White Light Flashing |
Linkage Method |
N/A |
Output Notification |
Message Push |
DEEP LEARNING FUNCTION :- |
|
Multi-Target-Type Detection |
Supports Simultaneous Detection and Capture of Human Body and Vehicle |
Face Capture |
N/A |
Face Comparison |
N/A |
GENERAL :- |
|
Package Contents |
VIGI Network Camera
Quick Start Guide
Waterproof Cable Attachments
Mounting Accessories |
Operating Temperature |
-30–60 °C |
Storage Temperature |
-40–60 °C |
Storage Humidity |
95% or Less (Non-Condensing) |
Operating Humidity |
95% or Less (Non-Condensing) |
Material |
Plastic |
Net Weight |
0.28 Kg |
Power Supply |
12V DC ± 5%, 5.5mm Coaxial Power Plug
PoE (802.3at, class 0) |
Power Consumption |
Maximum: 7 W
Typical (Day Mode): 1.5 W
Typical (Night Mode with IR LED): 2.5 W
Typical (Night Mode with White LED): 2.8 W |
Protection |
IP67, IK10 |
Product Dimensions (L x W x H) |
Φ115x85.7 mm |
Certifications |
CE, NTRA, VCCI, KC, BSMI, FCC, IC |
