Image Sensor |
1/3” Progressive Scan CMOS |
Shutter Speed |
1/3 to 1/10000 s |
Slow Shutter |
Yes |
Minimum Illumination |
0.005 Lux; 0 Lux with IR/white light |
Day/Night Mechanism |
IR Cut Filter |
Day/Night Switch |
Day/Night/Auto/Schedule-Switch |
Zoom |
3x Mixed Zoom |
Focal Length |
4-12 mm (Mixed Zoom) |
Aperture |
F1.6 |
FOV |
Diagonal FOV: 100°, Horizontal FOV: 84°, Vertical FOV: 46° |
Lens Mount |
M12*P 0.5 |
DORI Distance |
• 4 mm: Detect: 80 m (262 ft), Observe: 33 m (109 ft), Recognize: 16 m (52 ft), Identify: 8 m (26 ft)
• 8 mm: Detect: 150 m (493 ft), Observe: 63 m (205 ft), Recognize: 30 m (98 ft), Identify: 15 m (49 ft) |
Pan/Tilt Range |
Pan: 0° to 332°, Tilt: 0° to 120° |
Pan Speed |
Configurable from 1° to 55°/s; Preset Speed: 55°/s |
Tilt Speed |
Configurable from 1° to 40°/s; Preset Speed: 40°/s |
Manual Control Speed |
Configurable from 8° to 35°/s |
Presets |
300 |
Patrol Scan |
8 patrols, up to 8 presets for each patrol |
Power-off Memory |
Yes; Auto restore to previous PTZ and lens status after power failure |
Park Action |
Yes; Preset; Patrol Scan |
3D Positioning |
Yes |
Angle Adjustment (Manual) Range |
Pan: 0° to 332°, Tilt: 0° to 120° |
IR LED |
Quantity: 1, Range: 30m, Wavelength: 850nm |
White LED |
Quantity: 3, Range: 30m |
Illuminator On/Off Control |
Auto/Scheduled/Always on/Always off |
Max. Resolution |
2560 X 1440 |
Main Stream Frame Rate |
50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps; 60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps |
Main Stream Resolution |
2560x1440, 2304x1296, 2048x1280, 1920x1080, 1280x720 |
Sub-Stream Frame Rate |
50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps; 60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps |
Sub-Stream Resolution |
640x480, 352x288, 320x240 |
Bit Rate Control |
CBR, VBR |
Video Compression |
Main Stream: H.265+/H.265/H.264+/H.264; Sub-Stream: H.265/H.264 |
H.264 Type |
Main Profile/High Profile |
H.264+ |
Main Stream Supported |
H.265 Type |
Main Profile |
H.265+ |
Main Stream Supported |
Video Bit Rate |
Main Stream: 256 Kbps to 4 Mbps; Sub-Stream: 64 Kbps to 512 Kbps |
Image Settings |
Mirror, Brightness, Contrast, Saturation, Sharpness, Exposure, WDR, White Balance, Prevent Overexposure to Infrared Light, HLC Adjustable by Client Software |
Image Enhancement |
BLC/3D DNR/HLC/SmartIR |
Wide Dynamic Range |
DWDR |
SNR |
≥ 52 dB |
Image Parameters Switch |
Yes |
Privacy Mask |
Up to 4 Masks |
ROI |
1 Region |
OSD Setting |
Yes |
Audio Communication |
Two-Way Audio |
Audio Input |
Yes |
Audio Output |
Yes |
Audio Compression |
Yes |
Audio Sampling Rate |
8KHz |
Environment Noise Filtering |
Yes |
Audio Bit Rate |
64 Kbps(G.711 alaw) |
Protocol |
TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS |
ONVIF |
Yes |
API |
Open Network Video Interface (Profile S) |
Simultaneous Live View |
3 Main Streams & 3 Sub-Streams |
Client |
VIGI App, VIGI Security Manager, VIGI NVR, Web |
Web Browser |
Google Chrome® 57 and above, Firefox® 52 and above, Safari® 11 and above, Microsoft® Edge 91 and above |
Cloud |
Yes |
Security |
Password Protection, HTTPS Encryption, IP Address Filter, Digest Authentication |
Smart Event |
Human & Vehicle Classification, Area Intrusion Detection, Line-Crossing Detection, People Detection, Vehicle Detection, Region Entering Detection, Region Exiting Detection, Object Abandoned Detection, Object Removal Detection |
Basic Event |
Motion Detection, Video Tampering Detection, Exception ( Illegal Login) |
Alarm Linkage |
Memory Card Video Recording, Message Push, Audible Warning, White Light Flashing |
Linkage Method |
N/A |
Output Notification |
Message Push |
