| Camera :- |
|
| Image Sensor |
1/2.7" CMOS |
| Effective Pixels |
3200 (H) × 1800 (V) |
| Scanning System |
Progressive |
| Electronic Shutter Speed |
Auto/Manual 1/3 s–1/100,000 s |
| Minimum Illumination |
0.003 [email protected] (Color, 30 IRE)
0.0003 [email protected] (B/W, 30 IRE)
0 lux (illuminator on) |
| S/N Ratio |
56 dB |
| IR Distance |
30 m (98.43 ft) (IR)
30 m (98.43 ft) (warm light) |
| IR On/Off Control |
Auto / Manual |
| Illuminator Number |
1 (IR LED)
1 (warm light) |
| Pan/Tilt/Rotation Range |
Pan: 0°–360°
Tilt: 0°–78°
Rotation: 0°–360° |
| Lens :- |
|
| Lens Type |
Fixed-focal |
| Mount Type |
M12 |
| Focal Length |
2.8 mm; 3.6 mm |
| Field of View |
2.8 mm: H: 97°; V: 70°; D: 128°
3.6 mm: H: 78°; V: 58°; D: 102° |
| Iris Type |
Fixed |
| Close Focus Distance |
2.8 mm: 1.5 m (4.92 ft)
3.6 mm: 2.2 m (7.22 ft) |
| DORI Distance |
Lens | Detect | Observe | Recognize | Identify
2.8 mm | 66.0 m (216.54 ft) | 26.4 m ( 86.61 ft) | 13.2 m (43.31 ft) | 6.6 m (21.65 ft)
3.6 mm | 78.0 m (255.91 ft) | 31.2 m ( 102.36 ft) | 15.6 m (51.18 ft) | 7.8 m (25.59 ft) |
| Intelligent :- |
|
| IVS (Perimeter Protection) |
Tripwire; intrusion (Support the classification and accurate detection of vehicle and human) |
| SMD 4.0 |
Less false alarm, longer detection distance |
| Smart Search |
Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos. |
| Quick Pick |
With AI NVR, quickly pick up the human/vehicle targets that users are interested in from SMD events |
| AI SSA |
Adopt deep learning algorithms to adjust the parameters of the image to suit the conditions. |
| Video :- |
|
| Video Compression |
H.265; H.264; H.264H; H.264B; MJPEG (Only supported by the sub stream) |
| Smart Codec |
Smart H.265+; Smart H.264+ |
| AI Coding |
AI H.265; AI H.264 |
| Video Frame Rate |
Main stream:3200 × 1800 @(1 fps–25/30 fps)
Sub stream: 704 × 576@(1 fps–25 fps)/704 × 480@(1 fps–30 fps)
Third stream: 1920 × 1080@(1 fps–25/30 fps) |
| Stream Capability |
3 streams |
| Resolution |
6M (3200 × 1800); 5M (2880 × 1620/2960 × 1668); 4M (2688 × 1520/2560 × 1440); 3M 2304×1296/2048 × 1536); 1080p (1920×1080); 1.3M (1280 × 960); 720P(1280×720); D1 (704× 576/704×480); VGA(640 × 480); CIF (352×288/352×240) |
| Bit Rate Control |
CBR/VBR |
| Video Bit Rate |
H.264: 32kbps–8192 kbps
H.265:12kbps–8192 kbps |
| Day/Night |
Auto (ICR)/Color/B/W |
| BLC |
Yes |
| HLC |
Yes |
| WDR |
120 dB |
| Scene Self-adaptation |
Yes |
| White Balance |
Auto; natural; street lamp; outdoor; manual; regional custom |
| Gain Control |
Auto; manual |
| Noise Reduction |
3D NR |
| Motion Detection |
OFF/ON (4 areas) |
| Region of Interest (RoI) |
Yes (4 areas) |
| Smart Illumination |
Yes |
| Defog |
Yes |
| Image Rotation |
0°/90°/180°/270° (Support 90°/270° with 2688 × 1520 resolution and lower) |
| Mirror |
Yes |
| Privacy Masking |
8 areas |
| Audio :- |
|
| Built-in MIC |
Yes |
| Audio Compression |
PCM; G.711a; G.711Mu; G.726; G.723 |
| Alarm :- |
|
| Alarm Event |
No SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; motion detection; video tampering; tripwire; intrusion; scene changing; audio detection; voltage detection; external alarm; SMD; security exception |
| Network :- |
|
| Network |
RJ-45 (10/100 Base-T) |
| SDK and API |
Yes |
| Cyber Security |
Video encryption; firmware encryption; configuration encryption; Digest; WSSE; account lockout; security logs; IP/MAC filtering; generation and importing of X.509 certification; syslog; HTTPS; 802.1x; trusted boot; trusted execution; trusted upgrade |
| Protocol |
IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP ; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; SAMBA; PPPoE; SNMP |
| Interoperability |
ONVIF (Profile S/Profile G/Profile T); CGI; Milestone; P2P; RTMP |
| User/Host |
20 (Total bandwidth: 72 M) |
| Storage |
FTP; SFTP; Micro SD card (Support max. 256 G); NAS |
| Browser |
IE: IE8/9/11
Chrome
Firefox |
| Management Software |
Smart PSS; DSS; DMSS |
| Mobile Phone |
iOS; Android |
| Certification :- |
|
| Certification |
CE-LVD: EN 62368-1;
CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU;
FCC: 47 CFR FCC Part 15, Subpart B;
UL/CUL:UL62368-1 & CAN/CSA C22.2 No. 62368-1-14 |
| Port :- |
|
| Audio Input |
1 channel (RCA port) |
| Audio Output |
1 channel (RCA port) |
| Alarm Input |
1 channel in: 5 mA 3V–5 VDC |
| Alarm Output |
1 channel out: 300 mA 12 VDC |
| Power :- |
|
| Power Supply |
12 VDC/PoE (802.3af) |
| Power Consumption |
Basic: 3.7 W (12 VDC); 4.8 W (PoE)
Max. (pulling stream+warning light+speaker+warm light on): 8.3 W (DC12 V) 8.8 W (POE) |
| Environment :- |
|
| Operating Conditions |
–40 °C to +60 °C (–40 °F to +140 °F)/Less than 95% RH |
| Storage Conditions |
–40 °C to +60 °C (–40 °F to +140 °F) |
| Protection Grade |
IP67 |
| Structure :- |
|
| Casing |
Metal |
| Dimensions |
110.9 mm × Φ122.0 mm (4.37" × Φ4.80") |
| Net Weight |
745 g (1.64 lb) |
| Gross Weight |
915 g (2.02 lb) |
| Color |
Black |
