Camera :- |
|
Image Sensor |
1/3" CMOS |
Effective Pixels |
2688 (H) × 1520 (V) |
ROM |
128 MB |
RAM |
512 MB |
Scanning System |
Progressive |
Electronic Shutter Speed |
Auto/Manual 1/3 s–1/100,000 s |
Minimum Illumination |
0.005 [email protected] (Color, 30 IRE)
0.0005 [email protected] (B/W, 30 IRE)
0 lux (Illuminator on) |
S/N Ratio |
56 dB |
IR Distance |
50 m (164.04 ft) |
IR On/Off Control |
Auto / Manual |
Illuminator Number |
3 (IR LED) |
Pan/Tilt/Rotation Range |
Pan: 0°–355°; Tilt: 0°–80°; Rotation: 0°–355° |
Lens :- |
|
Lens Type |
Fixed-focal |
Mount Type |
M12 |
Focal Length |
2.8 mm; 3.6 mm: 6 mm |
Field of View |
2.8 mm: Horizontal:102°; vertical: 54°; diagonal: 121°
3.6 mm: Horizontal:84°; vertical: 42°; diagonal: 101°
6 mm: Horizontal:52°; vertical: 28° ; diagonal: 61° |
Iris Type |
Fixed |
Close Focus Distance |
2.8 mm: 1.1 m (3.6 ft)
3.6 mm: 1.7 m (5.6 ft)
6 mm: 3.2 m (10.5 ft) |
DORI Distance |
Lens | Detect | Observe | Recognize | Identify
2.8 mm | 66.0 m (216.54 ft) | 26.4 m ( 86.61 ft) | 13.2 m (43.31 ft) | 6.6 m (21.65 ft)
3.6 mm | 78.0 m (255.91 ft) | 31.2 m ( 102.36 ft) | 15.6 m (51.18 ft) | 7.8 m (25.59 ft) |
Intelligent :- |
|
IVS (Perimeter Protection) |
Tripwire; intrusion (Support the classification and accurate detection of vehicle and human) |
SMD 3.0 |
Less false alarm, longer detection distance |
Smart Search |
Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos. |
Face Detection |
Face detection; track; snapshot; snapshot optimization; optimal face snapshot upload; face enhancement; face exposure; face snapshot set as face or one-inch photo; 3 snapshot strategies (real-time snapshot, optimization snapshot, and quality priority); face angle filter; optimization time setting |
Video :- |
|
Video Compression |
H.265; H.264; H.264H; H.264B; MJPEG (Only supported by the sub stream) |
Smart Codec |
Smart H.265+; Smart H.264+ |
AI Coding |
AI H.265; AI H.264 |
Video Frame Rate |
Main stream: 2688 × 1520 @ (1–25/30) fps
Sub stream 1: 704 × 576 @ (1–25 fps)/704 × 480 @ (1–30 fps)
Sub stream 2: 1920 × 1080 @ (1–25/30 fps)
Sub stream 3: 1280 × 720 @ (1–25/30 fps) |
Stream Capability |
4 streams |
Resolution |
4M (2688 × 1520); 3.6M (2560 × 1440); 3M (2048 × 1536); 3M (2304×1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); CIF (352 × 288/352 × 240); VGA (640 × 480) |
Bit Rate Control |
CBR/VBR |
Video Bit Rate |
H.264: 32kbps–8192 kbps
H.265:12kbps–8192 kbps |
Day/Night |
Auto (ICR)/Color/B/W |
BLC |
Yes |
HLC |
Yes |
WDR |
120 dB |
Scene Self-adaptation |
Yes |
White Balance |
Auto; natural; street lamp; outdoor; manual; regional custom |
Gain Control |
Auto; manual |
Noise Reduction |
3D NR |
Motion Detection |
OFF/ON (4 areas) |
Region of Interest (RoI) |
Yes (4 areas) |
Smart Illumination |
Yes |
Defog |
Yes |
Image Rotation |
0°/90°/180°/270° (Support 90°/270° with 2688 × 1520 resolution and lower) |
Mirror |
Yes |
Privacy Masking |
4 areas |
Audio :- |
|
Audio Compression |
G.711a; G.711Mu; PCM; G.726; G.723 |
Alarm :- |
|
Alarm Event |
No SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; motion detection; video tampering; tripwire; intrusion; scene changing; audio detection; voltage detection; external alarm; SMD; security exception |
Network :- |
|
Network |
RJ-45 (10/100 Base-T) |
SDK and API |
Yes |
Cyber Security |
Video encryption; firmware encryption; configuration encryption; Digest; WSSE; account lockout; security logs; IP/MAC filtering; generation and importing of X.509 certification; syslog; HTTPS; 802.1x; trusted boot; trusted execution; trusted upgrade |
Protocol |
IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP ; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; SAMBA; PPPoE; SNMP |
Interoperability |
ONVIF (Profile S/Profile G/Profile T); CGI; Milestone; P2P; RTMP |
User/Host |
20 (Total bandwidth: 72 M) |
Storage |
FTP; SFTP; Micro SD card (Support max. 256 G); NAS |
Browser |
IE: IE8/9/11
Chrome
Firefox |
Management Software |
Smart PSS; DSS; DMSS |
Mobile Phone |
iOS; Android |
Certification :- |
|
Certification |
CE-LVD: EN 62368-1;
CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU;
FCC: 47 CFR FCC Part 15, Subpart B;
UL/CUL:UL62368-1 & CAN/CSA C22.2 No. 62368-1-14 |
Port :- |
|
Audio Input |
1 channel (RCA port) |
Audio Output |
1 channel (RCA port) |
Alarm Input |
1 channel in: 5 mA 3V–5 VDC |
Alarm Output |
1 channel out: 300 mA 12 VDC |
Power :- |
|
Power Supply |
12 VDC/PoE (802.3af) |
Power Consumption |
Basic: 3.7 W (12 VDC); 4.8 W (PoE)
Max. (pulling stream+warning light+speaker+warm light on): 8.3 W (DC12 V) 8.8 W (POE) |
Environment :- |
|
Operating Conditions |
–40 °C to +60 °C (–40 °F to +140 °F)/Less than 95% RH |
Storage Conditions |
–40 °C to +60 °C (–40 °F to +140 °F) |
Protection Grade |
IP67; IK10 |
Structure :- |
|
Casing |
Metal |
Dimensions |
89.1 mm × Φ111.7 mm (3.5" × Φ4.4") |
Net Weight |
516 g (1.14 lb) |
Gross Weight |
670 g (1.48 lb) |
