Projector type |
1-Chip DLP projector |
Panel size |
17.0 mm (0.67 in) diagonal (16:10 aspect ratio) |
Display method |
DLP chip x 1, DLP projection system |
Number of pixels |
2,304,000 (1920 x 1200 pixels) |
Light source |
Laser diodes |
Light output |
5,000 lm*1/5,200 lm (Center) |
Time until light output declines to 50 %5 |
20,000 hours |
Resolution |
1920 x 1200 pixels |
Contrast ratio2 |
20,000:1 (Full On/Full Off) |
Screen size (diagonal) |
1.02–7.62 m (40–300 in), 16:9 aspect ratio |
Center-to-corner zone ratio2 |
0.85 |
Lens |
Fixed (throw ratio: 0.8:1), powered focus, F 1.75, f 11.9 mm |
Vertical |
±4.4 % (powered) |
Horizontal |
±2.1 % (powered) |
Keystone correction range |
Vertical: ±25 °, Horizontal: ±20 ° |
Installation |
Ceiling/floor, front/rear, free 360-degree installation |
HDMI IN 1/2 |
HDMI 19-pin x 2 (Compatible with HDCP 2.3, Deep Color, 4K/60p signal input*4), CEC supported |
COMPUTER IN |
D-sub HD 15-pin (female) x 1 (RGB/YPBPR/YCBCR) |
COMPUTER 2 IN/1 OUT |
D-sub HD 15-pin (female) x 1 (RGB/YPBPR/YCBCR) |
VIDEO IN |
Pin jack x 1 (composite video) |
AUDIO IN 1 |
Pin jack x 1 (L, R) |
AUDIO IN 2/3 |
M3 x 1/M3 x 1 |
AUDIO OUT |
M3 x 1 (Variable) |
SERIAL IN |
D-sub 9-pin (female) x 1 for external control (RS-232C compliant) |
DIGITAL LINK |
RJ-45 x 1 for network and DIGITAL LINK connections (HDBaseT compliant), PJLink (Class 2) compatible, 100Base-TX, Art-Net compatible, HDCP 2.3 compatible, Deep Color compatible, 4K/60p signal input*4 |
LAN |
RJ-45 x 1 for network connection, PJLink (Class 2) compatible, 10Base-T/100Base-TX, Art-Net compatible |
USB |
USB connector (Type A) x 1 (Output 5 V/2 A) |
Power supply |
AC 100–240 V, 50/60 Hz |
Maximum power consumption |
465 W (5.0–2.0 A) (0.5 W with Standby Mode set to ECO, 10 W with Standby Mode set to NORMAL) |
On-mode power consumption (Operating mode) |
[NORMAL]: 370 W
[ECO]: 295 W
[QUIET]: 295 W |
Cabinet materials |
Molded plastic |
Operation noise |
27 dB (Quiet Mode), 32 dB (Normal Mode) |
Dimensions (W x H x D) |
498 x 168*5 x 481 mm (19 5/8 x 6 5/8*5 x 18 15/16 ) |
Weight |
Approx. 16.4 kg (36.1 lbs) |
