| Projector type |
1-Chip DLP projector |
| DLP Chip | Panel Size |
17.0 mm (0.67 in) diagonal ( Panel size 16:10 aspect ratio) |
| DLP Chip | Display Method |
DLP chip x 1, DLP projection system |
| DLP chip | Number of Pixels |
2,304,000 (1920 x 1200 pixels) |
| Light Source |
Laser diodes |
| Light output |
6,000 lm (Normal)*1 /6,200 lm (Center)*2 / 4,800 lm (Eco)*1 /2,400 lm (Long Life 1)*1 / 2,000 lm (Long Life 2)*1 /1,600 lm (Long Life 3)*1 |
| Time until light output declines to 50 %*3 |
20,000 hours (Normal)/24,000 hours (Eco) |
| Resolution |
1920 x 1200 pixels |
| Contrast Ratio*1 |
10,000:1 (Full On/Full Off, Dynamic Contrast [3] ) |
| Screen size [diagonal] |
1.27–15.24 m (50–600 in), 1.27–5.08 m (50–200 in) with ET-DLE055, 2.54–8.89 m (100–350 in) with ET-DLE035, 2.54–10.16 m (100–400 in) with ET-DLE020, 16:10 aspect ratio |
| Center-to-corner zone ratio*1 |
90% |
| Lens |
With supplied lens: Powered zoom (throw ratio 1.71–2.41:1), powered focus F 1.7–1.9, f 25.6–35.7 mm Without lens: Optional powered zoom/focus lenses |
| Lens shift*4 | Vertical(From the origin point of the lens mounter) |
+50 %, -16 % (+40 %, -16 % with ET-DLE060) (powered) |
| Lens shift*4 | Horizontal(From the origin point of the lens mounter) |
+30 %, -10 % (+10 %, -20 % with ET-DLE020, +19 %, -10 % with ET-DLE060, +28 %, -10 % with ET-DLE105/ET-DLE085) (powered) |
| Keystone Correction Range |
Vertical: ±40 ° (±5 ° with ET-DLE020, ±16 ° with ET-DLE060, ±22 ° with ET-DLE105/ET-DLE085/ET-DLE055, +5 ° with ET-DLE035), Horizontal: ±15 ° (±10 ° with ET-DLE060) (cannot be operated with ET-DLE035/ET-DLE020) |
| Keystone correction range with optional ET-UK20 Upgrade Kit |
Vertical: ±45 ° (±16 ° with ET-DLE060, ±40 ° with ET-DLE150/ET-DLE250/ET-DLE170, ±22 ° with ET-DLE105/ET-DLE085/ET-DLE055), Horizontal: ±40 ° (±10 ° with ET-DLE060, ±15 ° with ET-DLE105/ET-DLE085/ET-DLE055) When [VERTICAL KEYSTONE] and [HORIZONTAL KEYSTONE] are used simultaneously, correction cannot be made exceeding a total of 55 °. |
| Terminals | SDI In |
BNC x 1: 3G/HD/SD-SDI input |
| Terminals | HDMI In |
HDMI 19-pin x 1 (Compatible with HDCP 2.2, Deep Color, 4K/60p signal input*5 ) |
| Terminals | DVI-D In |
DVI-D 24-pin x 1 (DVI 1.0 compliant, compatible with HDCP, compatible with single link only) |
| Terminals | RGB 1 In |
RGB x 1 (BNC x 5): RGB/YPBPR/YCBCR |
| Terminals | RGB 2 In |
D-sub HD 15-pin (female) x 1: RGB/YPBPR/YCBCR |
| Terminals | Serial/Multi Projector Sync In |
D-sub 9-pin (female) x 1 for external control (RS-232C compliant) |
| Terminals | Serial/Multi Projector Sync Out |
D-sub 9-pin (male) x 1 for link control |
| Terminals | REMOTE 1 IN |
M3 x 1 for wired remote control |
| Terminals | REMOTE 1 OUT |
M3 x 1 for link control (for wired remote control) |
| Terminals | Remote 2 In |
D-sub 9-pin (female) x 1 for external control (parallel) |
| Terminals | DIGITAL LINK |
RJ-45 x 1 for network and DIGITAL LINK connections (HDBaseT compliant), PJLink (Class 2) compatible, 100Base-TX, Art-Net compatible, HDCP 2.2 compatible, Deep Color compatible, 4K/60p signal input*5 |
| Terminals | LAN |
RJ-45 x 1 for network connection, PJLink (Class 2) compatible, 10Base-T/100Base-TX, Art-Net compatible |
| Power Supply |
AC 100–240 V, 50/60 Hz |
| Power Consumption |
490 W (Normal)/395 W (Eco)/ 200 W (Long Life 1)/180 W (Long Life 2)/ 160 W (Long Life 3) |
| Operation noise*1 |
35 dB (Normal) |
| Dimensions (W x H x D) |
With supplied lens: 498 x 200*6 x 581 mm (19 19/32" x 7 7/8"*6 x 22 7/8") Without lens: 498 x 200*6 x 538 mm (19 19/32" x 7 7/8"*6 x 21 3/16") |
| Weight*7 |
With supplied lens: Approx. 22.1 kg (48.7 lbs)
Without lens: Approx. 21.3 kg (47.0 lbs) |
| Operating Environment |
Operating temperature: 0–45 °C (32–113 °F)*8 , operating humidity: 10–80 % (no condensation) |
| Applicable Software |
Logo Transfer Software, Multi Monitoring & Control Software, Early Warning Software, Geometry Manager Pro (ET-UK20 Upgrade Kit, ET-CUK10 Auto Screen Adjustment Kit), Smart Projector Control for iOS/Android |
| Note |
*1 Measurement, measuring conditions, and method of notation all comply with ISO/IEC 21118: 2012 international standards. Value is average of all products when shipped. *2 Average light-output value of all shipped products measured at center of screen in NORMAL Mode. *3 Aroundthis time, light output will have decreased by approximately 50 %. IEC62087: 2008 Broadcast contents, NORMAL Mode, Dynamic Contrast [ON], under conditions with 35 °C (95 °F), 700 m (2,297 ft) above sea level, and 0.15 mg/m3 of particulate matter. Estimated time until light outputdeclines to 50 % varies depending on environment. *4 Lens shift is not supported on the ET-DLE055, and the optical axis is fixed with the ET-DLE035. *5 4K signals are converted to the projector's resolution (1920 x 1200 pixels) upon projection. Supported terminals: DIGITAL LINK/HDMI ®.*6 Excluding legs. *7 Average value. May differ depending on the actual unit. |
