Ubiquiti NBE-2AC-13 NanoBeam 2AC High-Performance airMAX Bridge Antenna

Ubiquiti NBE-2AC-13 NanoBeam 2AC High-Performance airMAX Bridge Antenna

Name: Ubiquiti NBE-2AC-13 NanoBeam 2AC High-Performance airMAX Bridge Antenna
Brand: Ubiquiti
SKU: NBE-2AC-13
Price: 183 AUD
Availability: InStock

SKU : NBE-2AC-13

Brand : Ubiquiti

Availablity : Online Only, In Stock
Ships within 1 and 3 days from our Seven Hills, NSW warehouse or Pickup in 3 to 4 days

Enclosure material: UV-stabilized plastic, Networking interface: (1) GbE RJ45 port, Power method: Passive PoE (Pairs 4, 5+; 7, 8 Return), Power Supply: 24V, 0.5A Gigabit PoE adapter (Included), 01 Year Limited Warranty, NBE-2AC-13.

Ask a question about this product

$183.00

Buy Now

Estimated Shipping

Find

For Bulky items and non-metro Australia a different shipping will be quoted on order receipt.

No surcharge On Credit Card, AMEX or Paypal. American express, master card, nab, Paypal, visa

Description
Specifications
Reviews

Product Description

Manufacture # Ubiquiti | Model # NBE-2AC-13

The NanoBeam 2AC directs RF energy in a tighter beamwidth. With the focus in one direction, the NanoBeam 2AC blocks or spatially filters out noise, so noise immunity is improved. This feature is especially important in an area crowded with other RF signals of the same or similar frequency.

Features:

Access Point PtMP airMAX Mixed Mode
airMAX ac Protocol Support
Long-Range Point-to-Point (PtP) Link Mode
Automatic Channel Selection
Automatic Distance Selection (ACK Timing)
Strongest WPA2 Security

Overview:

Enclosure material: UV-stabilized plastic
Networking interface: (1) GbE RJ45 port
Power method: Passive PoE (Pairs 4, 5+; 7, 8 Return)
Power Supply: 24V, 0.5A Gigabit PoE adapter (Included)

Manufacturer Warranty: 01 Year Limited Warranty

Technical Specifications

Mechanical:-
Dimensions	189 x 189 x 125 mm (7.4 x 7.4 x 4.9")
Weight	530 g (1.2 lb)
Enclosure material	UV-stabilized plastic
Mounting	Pole mount kit (Included) Wall mount (Not included) Window mount (Not included)
Wind loading	45.4 N at 200 km/h (10.2 lbf at 125 mph)
Wind survivability	200 km/h (125 mph)
Hardware:-
Networking interface	(1) GbE RJ45 port
Power method	Passive PoE (Pairs 4, 5+; 7, 8 Return)
Power Supply	24V, 0.5A Gigabit PoE adapter (Included)
Max. power consumption	7.5W
ESD/EMP protection	Air/contact: ± 24kV
LEDs	Power, Ethernet, (4) signal strength
Salt fog test	IEC 68-2-11 (ASTM B117) Equivalent: MIL-STD-810 G method 509.5
Vibration test	IEC 68-2-6
Temperature shock test	IEC 68-2-14
UV test	IEC 68-2-5 at 40° C (104° F) Equivalent: ETS 300 019-1-4
Wind-driven rain test	ETS 300 019-1-4 Equivalent: MIL-STD-810 G method 506.5
Operating temperature	-40 to 80° C (-40 to 176° F)
Operating humidity	5 to 95% noncondensing
System:-
Gain	13 dBi
Channel sizes	PtP Mode: 10/20/40 MHz PtPM Mode: 10/20/40 MHz
Max. VSWR	1.5:1
Polarization	Dual linear
Operating Frequency (MHz):-
Worldwide	2412 - 2472 MHz
USA	2412 - 2462 MHz
Management Radio (MHz):-
Worldwide	5150 - 5250 MHz
US/CA	U-NII-3: 5725 - 5850 MHz
