Ubiquiti Networks Loco5AC Nanostation 5GHz MIMO antenna - 5 Pack

Ubiquiti Networks Loco5AC Nanostation 5GHz MIMO antenna - 5 Pack

Name: Ubiquiti Networks Loco5AC Nanostation 5GHz MIMO antenna - 5 Pack
Brand: Ubiquiti
SKU: Loco5AC-5
Price: 447 AUD
Availability: InStock

SKU : Loco5AC-5

Brand : Ubiquiti

Availablity : on order
On Order items usually have to be ordered in and may take bit longer to get them delivered from our Seven Hills, NSW warehouse

Networking interface: (1) GbE RJ45 port, Power method: Passive PoE 2-Pair (Pairs 4, 5+; 7, 8 Return), LEDs: Power, Ethernet, (4) signal strength, Gain: 13 dBi, Channel bandwidths: 10/20/30/40/50/60/80 MHz, Cross-pol isolation: 20 dB min., Warranty: 01 Year, Loco5AC-5.

Ask a question about this product

$447.00

Buy Now

Estimated Shipping

Find

For Bulky items and non-metro Australia a different shipping will be quoted on order receipt.

No surcharge On Credit Card, AMEX or Paypal. American express, master card, nab, Paypal, visa

Description
Specifications
Reviews

Product Description

Manufacture # Ubiquiti | Model # Loco5AC-5

The NanoStation AC and NanoStation AC loco take the same concept to the future with sleek form factors, along with integrated airMAX (MIMO TDMA protocol) technology and dedicated Wi-Fi management. The radio and antenna are combined to create a more efficient and compact CPE. The NanoStation AC and

Features:

Sleek Industrial Design
Management Wi-Fi Radio
Improved Surge Protection
Now with airOS®8
10km+ Range

Overview:

Networking interface: (1) GbE RJ45 port
Power method: Passive PoE 2-Pair (Pairs 4, 5+; 7, 8 Return)
LEDs: Power, Ethernet, (4) signal strength
Gain: 13 dBi
Channel bandwidths: 10/20/30/40/50/60/80 MHz
Cross-pol isolation: 20 dB min.

Manufacturer Warranty: 01 Year Limited Warranty

Technical Specifications

Mechanical :-
Dimensions	179 x 77.5 x 59.1 mm (7.05 x 3.05 x 2.33")
Weight	0.18 kg (6.35 oz)
Enclosure material	UV-stabilized plastic
Mounting	Pole mounting kit (Included)
Hardware :-
Networking interface	(1) GbE RJ45 port
Power method	Passive PoE 2-Pair (Pairs 4, 5+; 7, 8 Return)
Power supply	24V, 0.3A Gigabit PoE supply*
Supported voltage range	24V ±10%
Max. power consumption	8.5W
LEDs	Power, Ethernet, (4) signal strength
Operating temperature	-40 to 70° C (-40 to 158° F)
Operating humidity	5 to 95% noncondensing
Certifications	CE, FCC, IC
System :-
Gain	13 dBi
Channel bandwidths	10/20/30/40/50/60/80 MHz
Cross-pol isolation	20 dB min.
Max. VSWR	1.8:1
Beamwidth	45° (H-pol) / 45° (V-pol) / 45° (Elevation)
Polarization	Dual linear
Operating Frequency (MHz) :-
Worldwide	5150-5875 MHz
USA
U-NII-1	5150-5250 MHz
U-NII-2A	5250-5350 MHz
U-NII-2C	5240-5725 MHz
U-NII-3	5725-5850 MHz
Management Radio (MHz) :-
Worldwide	2412 - 2472 MHz
US/CA	2412 - 2462 MHz
